Plastic clips are versatile and useful items, often used to seal bags of food or outdoor gear. They are also commonly used in designing plastic parts, such as pen caps, bottle caps, and electronic housings. When designing plastic clips, it is important to consider factors such as stress distribution, flexibility, and recovery to ensure the clip is durable and effective. Poorly designed clips may break or fail to recover after repeated use. To create a functional plastic clip, one can follow certain steps, such as using bendy straws to form the clip-on part that slides over packaging or employing specific techniques to increase the effective length of the clip's flexing arm.
| Characteristics | Values |
|---|---|
| Types of snap locks | Cantilever, Annular, Torsional |
| Most common type of snap lock | Cantilever snap lock |
| Torsional snap locks ideal for | Applications requiring a radial lock like a push-release lock, threaded-bottle-cap safety lock, or a ratchet lock |
| Ways to increase the arm's effective length | Looping or coiling the arm, notching the wall to which the clip is attached, designing the wall to flex slightly |
| Ways to reduce stress on the clip | Limiting the size of the hook at the end of the arm, using rounded corners and fillets at the base of the clip |
| Draft | Should be a minimum of 3 degrees, length should be no more than 8 times its thickness |
| Through-hole at the base of the clip | Should be significantly larger than the clip-head |
| Testing and validating | Use a finite element analysis (FEA) program to test and validate the strength and flexibility of a clip while it’s still a CAD model |
Explore related products
What You'll Learn
Making a bag clip from plastic straws
Plastic straws can be used to create a bag clip to prevent food from spilling out of a plastic bag. This is a simple and straightforward process that only requires two plastic straws. Firstly, select two bendy straws of your choice of colour. Cut just under the bendy part of one of the straws and then cut down the centre of that straw. This will be the "clip-on" part of the clip. Next, open up the straw lengthwise so that it opens cleanly and can slide over the packaging. Take the remaining uncut straw and cut small, even strips on the short side above the bendy part. Curl each cut straw length by running your nail along each length. This will form a flower shape at the end of the straw. You can add a pompom to the middle of the flower shape as an optional extra.
Now, grab the bag that needs to be sealed and fold the bag top over the straw with the flower shape. Take the straw that you cut down the middle and slide it over the folded part of the bag, pushing it down so that it sits snugly over the flower straw underneath the fold. Slide the straw all the way along the top of the bag and the flower straw so that it sits evenly. You can also cut the outer straw diagonally at the end to make it easier to slide on. You can now store your sealed bag.
This clip can be used on bags other than food bags, such as craft bags, to ensure small objects don't spill out.
There are also various ways to design more complex plastic clips, such as using snap locks, but these require more advanced equipment and knowledge.
