Attaching Screens: Plastic Lattice Guide

how to attach screen to plastic lattice

Adding a screen to a plastic lattice is a great way to increase privacy and keep out unwanted visitors such as rabbits and chipmunks. While some people suggest using hot glue or staples to attach the screen, others recommend using stainless steel or vinyl-specific adhesives for a more durable and polished look. Creating a frame for the lattice by cutting wood to size and screwing the pieces together can also help to improve privacy and keep the screen tight.

Characteristics Values
Adhesive Hot glue, Loc-Tite PowerGrab, or adhesives from a craft store
Mechanical Strips of wood lath or lattice screwed on as a backer behind the screen
Screws Stainless steel screws, 8 x 1 – 5/8″, and 10 x 3″

shunpoly

Use glue or adhesive

If you are looking to attach a screen to a plastic lattice, there are a variety of glues and adhesives that can be used. However, it is important to note that some plastic glues may melt the lattice, so it is recommended to test any adhesive on a small area first. One option is to use a two-part epoxy, but be sure to read the instructions carefully before use. Another option is to use a construction adhesive such as Loc-Tite PowerGrab, which is a strong general-purpose adhesive. If you want a clear adhesive, you could try using a hot glue gun, but be aware that some hot glues expand and may not give a polished look. You can also find a wide range of adhesives in your local craft store, including some that are specifically designed for use with plastic.

When using adhesives, you may need to get creative to keep the screen tight while the glue dries. One suggestion is to use a separate frame behind the lattice to hold the screen in place. Alternatively, you can use furring strips or lattice to wrap the screen around and then mechanically attach it to your frame. Another option is to use staples, but this may not be suitable if you want a seamless finish as you will need to cover the staples with a piece of wood.

shunpoly

Use staples

Using staples to attach a screen to a plastic lattice is a straightforward process, but it requires careful preparation and execution to ensure a secure and long-lasting installation. Here is a step-by-step guide on how to use staples for this task:

Prepare the Materials and Work Area:

Before beginning, gather the necessary materials, including staples, a staple gun or heavy-duty stapler, the plastic lattice, the screen, and any protective gear, such as gloves and eye protection. Choose a well-lit work area that provides enough space to lay out the lattice and screen comfortably.

Measure and Cut the Screen:

Measure the dimensions of the plastic lattice and cut the screen accordingly. Ensure that the screen is cut slightly larger than the lattice to allow for stretching and a snug fit. It is important to stretch the screen fairly tight before stapling to prevent sagging and ensure a neat appearance.

Position the Screen and Secure with Staples:

Place the screen over the plastic lattice, aligning it carefully. Starting from the centre and working outwards, use the staple gun or heavy-duty stapler to attach the screen to the lattice. Ensure that the staples are firmly embedded in the plastic lattice. Use staples that are long enough to penetrate the lattice and hold the screen securely.

Finish and Inspect:

After stapling, carefully examine the work to ensure that the screen is taut and securely attached to the plastic lattice. Check for any loose staples and use additional staples as needed to reinforce the attachment. Trim any excess screen material close to the staples, being careful not to cut the lattice itself.

Maintenance and Precautions:

Staples are a convenient and quick method for attaching screens to plastic lattice, but they may not be as durable as other methods, such as adhesives or mechanical fasteners. Over time, staples may loosen due to weather conditions or the natural expansion and contraction of the materials. Periodically inspect the staples and resecure any that have loosened.

shunpoly

Use screws

If you're looking to attach a screen to a plastic lattice, one method is to use screws. This can be done in several ways, depending on the specific application and requirements. Here's a step-by-step guide on how to use screws to attach a screen to a plastic lattice:

Prepare the Materials and Framework:

Before beginning the installation, gather the necessary materials, including rust-proof screws, washers, and any other hardware. Measure and cut the lattice panels to fit the dimensions of your frame. It is recommended to use stainless steel pan head screws with washers for outdoor applications, as they are rust-resistant.

Attach the Screen to the Lattice:

Lay the plastic lattice frame face down. Position the screen over the lattice, allowing a 1/4-inch gap on all sides to accommodate expansion and contraction due to weather changes. Use 1-inch pan head screws with washers to secure the screen to the lattice. Ensure that the screws are long enough to hold the screen firmly in place without puncturing through the visible side.

Secure the Lattice to the Frame:

If you are working with separate lattice panels and frames, you will need to attach them together securely. Position the lattice panel onto the frame and use screws to fasten them together. Drill screws at each point where the lattice meets the frame to ensure a strong hold. You may also need to secure the seams between multiple pieces of lattice using screws and washers.

Install the Framed Lattice:

Once the screen is attached to the lattice, and the lattice is secured to its frame, you can install the entire assembly onto your desired surface. This may involve using straps, T-hinges, or other hardware to attach the framed lattice to a porch, deck, or another structure. Ensure that the assembly is level and securely fastened to prevent any movement or sagging.

Tips and Considerations:

When screwing into plastic lattice, it is recommended to pre-drill pilot holes slightly larger than the screw size to accommodate the expansion and contraction of the plastic material. Additionally, when screwing into the framework, especially near the ends or sides, pre-drilling holes can help prevent the material from cracking or splitting. Always use rust-proof hardware and fasteners to ensure the longevity of your installation.

shunpoly

Build a frame

Building a frame for your plastic lattice privacy screen is a simple process that can be done on a budget. The first step is to decide on the size and shape of your frame. This will depend on the size of the area you want to screen off and the degree of privacy you require. Once you have a plan, it's time to gather your materials.

For a simple rectangular frame, you will need four pieces of wood of equal length for the sides, and four shorter pieces to join them together at the corners. You can use a mitre saw to cut the wood to the required length and ensure that the corners are joined at a neat right angle. Sand down any rough edges to ensure a smooth finish.

Before assembling the frame, it is a good idea to paint or treat the wood. Choose a paint that is suitable for outdoor use and consider a colour that will complement or match your plastic lattice. Allow the paint to dry completely before proceeding to the next step.

Now it's time to assemble your frame. Lay the pieces of wood out on a flat surface and use stainless steel screws to join the corners together. It is important to use stainless steel to prevent rust. Drill pilot holes to prevent the wood from splitting, and screw from the inside of the frame out. This will create a neat finish and ensure that the screws are not visible from the outside.

Once your frame is assembled, you can attach the plastic lattice. Cut the lattice to size, allowing for a few centimetres of overlap all the way around. You can use screws to attach the lattice to the frame, or you might prefer to use an adhesive. If using an adhesive, choose a glue that is suitable for use with plastic and be sure to follow the manufacturer's instructions. Stretch the lattice fairly tight and use weights or clamps to hold it in place while the glue dries.

shunpoly

Use strips of wood lath

One way to attach a screen to a vinyl lattice is to use strips of wood lath. You can use two strips of wood lath or 1x2, placing one behind the lattice and the other over the top of the screen to trim it. You can cut strips of lattice, about two cells wide, and screw them on as a backer behind the screen.

Before assembling the lattice, you can paint your frame. You will need to use stainless steel screws so they do not rust. You can use 8 x 1 - 5/8" screws to create the lattice patio screen and 10 x 3" screws to attach the privacy screen to the existing post. Remember to screw from the "inside" out.

When hanging your lattice screen, ensure that the screws are facing inward. You can also use vinyl lattice panels when building a DIY screen. You can purchase plastic/PVC lattice and cut it to size. You will then place your lattice on top and add the frame on top of the lattice.

Adhesives can also be used to attach the screen. Loc-Tite PowerGrab is a construction adhesive that can be used. However, you may need to get creative in keeping the screen tight while the glue sets.

Frequently asked questions

You can use hot glue, but only if it is weatherproof. You can also use adhesives specifically made for vinyl.

You can use staples, but only if the screen is stretched fairly tight. You can also use stainless steel screws.

This depends on the type of screen you are attaching. For a lattice patio screen, you can use 8 x 1 – 5/8″ screws. To attach the screen to an existing post, use 10 x 3″ screws.

You can cut strips of lattice, about two cells wide, and screw them on as a backer behind the screen.

Remember to screw from the “inside” out. You can also paint your frame before assembling the lattice.
