Designing a plastic hinge-pin is a complex process that requires careful consideration of various factors. Plastic is a reasonably weak material, and hinges require specific design elements to ensure they bend without flexing and can hold a substantial amount of weight. The hinge-pin, in particular, must be strong, especially at its attachment points, and the barrel should be stronger in the centre. This design will ensure the hinge is stronger than a constant diameter axis and barrel with the same build volume. To achieve this, the pin's diameter must be carefully calculated, and the material must be stiff and strong.
| Characteristics | Values |
|---|---|
| Type of pin | Solid pin, coiled-spring pin, cotter pin |
| Hinge type | Free-fit, Friction-fit |
| Material | Plastic, steel, tubing |
| Design | Living hinge, flush rivet |
| Installation | Driven in from each side, threaded hinge pin |
| Size | 40x40mm, scalable |
| Printing material | PLA, PETG, ABS, Nylon |
| Strength | Stronger at certain points, constant strength throughout |
Explore related products
What You'll Learn
Consider using a coiled-spring pin for lower costs and higher performance
When designing a plastic hinge, consider using a coiled-spring pin for lower costs and higher performance. Coiled-spring pins are a leading use case for hinges as they match or exceed the performance of solid pins while reducing costs. They are functional springs, formed from a strip of material rolled into coils, typically wound 2.25 times. The outer diameter of the pin should be larger than the diameter of the hole it is installed in, creating friction.
Coiled-spring pins can be used in both free-fit and friction-fit hinges. In a free-fit hinge, the pin is held tightly in one or two retaining holes, with the outside of the pin passing through a larger hole in the opposing part. The coiled-spring pin can be designed to have little to no friction or drag when the latch or handle rotates. In a friction-fit hinge, all holes should be sized identically, and the coiled-spring pin can be designed to have varying levels of resistance, from a slight drag to a fixed position.
Coiled-spring pins come in light, standard, and heavy-duty varieties, referring to the thickness of the material used. Light-duty pins are flexible and work well in plastic hinges, while heavy-duty pins can cause stress in lighter materials. Designers should consider the recovery and retention of the pin in free-fit applications, as well as the "free span" of the pin, or the distance it passes through a free-fit component. For better load distribution, the tight fit of the coiled pin should be in the outer members of the hinge.
Coiled-spring pins offer several benefits over solid pins. They simplify the design process as they do not require accommodating misalignment between holes to ensure friction. They can also absorb shock and vibration, resulting in fewer maintenance issues and a longer assembly life. Additionally, they conform to a wide range of hole tolerances and do not damage the plastic during insertion.
Gold Standard: Plastic Amex Cards Explained
You may want to see also
Explore related products
Ensure the hinge bends without flex and can hold weight
Plastic is not the ideal material for a hinge-pin, as it is reasonably weak and requires oversized dimensions to achieve stiffness and strength. However, if you are set on using plastic, there are some things you can do to ensure the hinge bends without flex and can hold weight.
Firstly, it is important to consider the design of the hinge. A coiled-spring pin can be used to lower costs and extend the life of the hinge. The type of fit is also important. A friction-fit hinge has resistance, which can vary from a slight drag to a level sufficient to hold components in a fixed position. This type of hinge is well-suited for holding weight. The minimum thickness of the outer members should be 1 to 1.5 times the diameter of the pin.
Secondly, the shaft of the hinge needs to be strong, especially at its attachment points. The barrel will be stronger at the centre, so the overall hinge will be stronger than a constant diameter axis and barrel in the same build volume. A fifty-fifty support-hinge ratio is a good option, with the profile of the hinge getting larger smoothly until the barrel area.
Finally, the material and printing process are important considerations. It is recommended to use PLA or PETG as the printing material, as ABS and Nylon bend too easily. The hinge should be printed vertically to get a smooth motion.
Attaching Plastic Purse Handles: A Step-by-Step Guide
You may want to see also
Explore related products
Design a free-fit hinge with little to no friction
To design a free-fit hinge with little to no friction, you can use a coiled spring pin. This type of hinge allows components to swing freely and independently of one another. The amount of friction in a free-fit hinge can be adjusted by changing the pin diameter or the size of the holes the pin goes through.
When designing a plastic hinge-pin with little to no friction, there are several factors to consider. Firstly, the size and placement of the circular nubs or protrusions that act as the rotation point are crucial. They should be large enough to provide stability and prevent unwanted movement, but not so large that they cause friction or binding. Proper alignment between the circular nubs and the corresponding recesses in the other part is also essential for a smooth and secure locking mechanism.
Another variation of the pin hinge design involves using plastic as the lever or pin that locks the hinge. The plastic lever is designed with a specific shape or cutout that engages with a corresponding feature on the opposite part. The locking mechanism should be secure when engaged and easy to release when desired. The flexibility of the plastic material used for the lever and pin is an important factor in ensuring smooth operation and durability.
When designing a free-fit hinge, the first step is to establish the maximum hole size in the retaining component for a tight fit. The coiled pin is then inserted, and the free diameter of the pin at the centre of the span is measured. A clearance factor is added to determine the minimum diameter of the free hole, usually 0.001 inches (0.02 mm). The required production tolerance is then added to assign the maximum diameter of the free hole.
For a free-fit hinge, the preinstalled diameter of the coiled pin is less important because it is the smallest holes in the handle that determine the final pin diameter. Designers must consider recovery and retention in free-fit applications, which depend on the diameter of the retaining hole and the "free span" of the pin. The "free span" refers to the distance a pin passes through a free-fit component. As the free span increases, the pin diameter will also increase as it recovers its preinstalled diameter.
