The Plastic Neutral Axis (PNA) is a crucial concept in engineering and mechanics, defining the line between tension and compression regions in a fully plastic shape or section. It is the axis where the sum of the yield strength times the areas above and below it are equal. While finding the centroid of a shape is a well-known concept for engineering students, determining the PNA is often not covered in-depth in introductory courses. The PNA is particularly relevant in plastic behaviour in bending, and its calculation can vary depending on the symmetry and material composition of the shape. For example, in a symmetric section made of a single material, the PNA falls at the mid-height. However, in asymmetric sections or those with asymmetric material distribution, the calculation becomes more complex, requiring assumptions and testing. Understanding the PNA is essential for structural analysis and design, especially in composite beam designs and when dealing with ductile materials like mild steel.
| Characteristics | Values |
|---|---|
| Definition | The Plastic Neutral Axis (PNA) is the dividing line between the tension and compression zones of a shape that has developed full plasticity. |
| Equation | Under pure bending, the resultant forces above and below the PNA must be equal, and those forces are equal to the integral (or summation) of the areas times their yield stresses. |
| Symmetric Shapes | When the shape is symmetric and composed of a single material, the Elastic Neutral Axis (ENA) and PNA are the same. |
| Asymmetric Shapes | When the shape is not symmetric about the x-axis, the ENA and PNA differ. This also applies to geometrically symmetric shapes with asymmetric material composition. |
| Location | The PNA is located inside the beam's top flange or very close to it. It can also be within the concrete slab, the flange of the steel beam, or the web of the steel beam section. |
| Centroid | The PNA is based on the line that halves the area of a mono-material shape, passing through the centroid. |
| Yield Stress | In a mono-material shape, the yield stress is the same for the entire shape, allowing for simplification of the general equation. |
| Bending | When a compressive axial force is applied to a rectangular section, it shifts the PNA by increasing the compression zone. |
Explore related products
What You'll Learn
- The Plastic Neutral Axis (PNA) is the line between tension and compression zones of a shape with full plasticity
- The PNA is found at the mid-height of any symmetric section made of one material
- When the shape is asymmetric, the Elastic Neutral Axis (ENA) and PNA differ?
- The PNA is based on the line that halves the area of a mono-material shape
- The PNA can be located inside the beam's top flange or near it for an economic solution
The Plastic Neutral Axis (PNA) is the line between tension and compression zones of a shape with full plasticity
The Plastic Neutral Axis (PNA) is a crucial concept in engineering and mechanics, serving as the dividing line between the tension and compression zones of a shape that has achieved full plasticity. This axis is instrumental in comprehending the behaviour of materials under stress and aids in designing structures that can withstand and distribute loads effectively.
In the context of a fully developed plastic hinge section subjected to pure bending, the PNA defines the boundary between regions experiencing tension and compression forces. This distinction is essential because, in the absence of a resultant axial force, these compressive and tensile forces must be equal and balanced to maintain equilibrium.
The PNA is particularly relevant when dealing with ductile materials, such as mild steel, which exhibit a large yield plateau on their stress-strain curves. In such materials, full development of a plastic hinge occurs when every portion of the material yields, allowing for a more straightforward analysis of plastic bending.
Determining the location of the PNA can be achieved through calculations involving the yield strength and areas above and below the axis. The general equation dictates that the sum of the yield strength multiplied by the areas above the PNA equals the sum of the yield strength multiplied by the areas below it. This equation simplifies for mono-material shapes, where the yield stress remains constant throughout.
It is important to note that the PNA and the Elastic Neutral Axis (ENA) may coincide in certain cases, such as when the shape is symmetric and composed of a single material. However, in asymmetric sections or those with asymmetric material distribution, the PNA and ENA differ, with the PNA based on the line that halves the area rather than a weighted average of centroids.
