Compression fittings are a great way to join plastic pipes together, especially when refurbishing and joining old pipes to new ones. They are easy to fit and adjust, and they come in various shapes and sizes, including straight reducers, elbows, and T connections. When fitting a compression joint, it's important to ensure that the rubber washer or sealing ring is not twisted to prevent leaks. The assembly process involves slotting on the screw cap, followed by the rubber seal, and then the body of the compression unit. For copper and plastic pipes, a liner is necessary to keep the end of the pipe perfectly round and protect it from damage.
Explore related products
What You'll Learn
Cutting plastic pipes
Selecting the Right Tools
The type of plastic tubing you are working with will determine the appropriate cutting tools. For PVC tubing, which is rigid and prone to cracking, use a sharp pipe cutter or a hacksaw to make straight cuts. If you're working with smaller pipes, scissor-type plastic cutters or ratchet-style cutters are effective but require more manual effort. For PEX tubing, which is flexible, you can bend it around corners without additional fittings. PE tubing, on the other hand, is lightweight and flexible, making it suitable for low-pressure applications.
Marking and Securing the Pipe
Before cutting, use a tape measure and a pencil to mark the pipe's surface where you want to make the cut. Secure the pipe firmly using a vise, clamp, miter box, or even duct tape to prevent it from moving during the cutting process. This step is crucial for achieving a straight cut.
Cutting the Pipe
Once the pipe is secured, slowly draw the hacksaw blade back and forth, ensuring that the cut remains straight. If using scissor-style cutters, apply pressure to the handles and slowly rotate the cutter around the pipe, continuing until you cut through the pipe. For pipe cutters, place the tubing inside and rotate the cutter while gradually tightening it until the pipe is cut through.
Deburring the Edges
After cutting, it is essential to remove any burrs or rough edges using a deburring tool or a utility knife. This step ensures that the tubing will fit smoothly into the compression fitting without damaging its components. Properly deburred edges contribute to a secure and leak-free connection by preventing issues that may arise from uneven surfaces.
Final Assembly
After cutting and deburring, it's time to assemble the compression fitting. Begin by sliding the compression nut onto the end of the plastic tubing, ensuring the threads face the open end of the tubing. Then, slide the ferrule (olive) onto the tubing, creating a tight seal when compressed. Finally, add the screw cap, tightening it with hand pressure to hold everything in place and ensure a complete seal.
India's Plastic Waste Disposal: A Sustainable Future?
You may want to see also
Explore related products
Assembly of the compression fitting
Next, slot on the body of the compression unit. When fitting to a pipe, put the nut on first, followed by the compression ring and finally the rubber sealing ring. The rubber sealing ring has a tapered edge that must be fitted with the narrow end facing toward the join. Bring the fitting in and push up so that the tapered edge is squeezed onto the fitting.
For additional security, hand-tighten the fitting and then tighten it further with a spanner until it is crimped on, ensuring that the olive compresses onto the pipe. You can also wrap PTFE tape around the olive for extra security.
It is important to note that compression fittings can be bulky, making them unsuitable for tight spaces. This can make it difficult to ensure that the rubber washer is not twisted and to prevent leaks.
Transforming Plastic Crates: Fabric-Covered Bliss
You may want to see also
Explore related products
Using a rubber seal
Compression fittings are used to connect two pipes or a pipe to a fixture or valve. They are a strong and reliable connection that tightens down a sleeve over a joint to prevent leaks. The fittings are made from a variety of materials, including plastic, stainless steel, and brass.
The process of fitting compression fittings using a rubber seal involves several steps. Firstly, ensure that you have cut the pipe to the correct length for your needs. This can be done using a hacksaw or plastic pipe cutters, ensuring a clean cut without any burrs.
Next, insert the tube into the compression fitting. Make sure the tube is bottomed on the fitting shoulder. The rubber seal, or 'O-ring', plays a crucial role in creating a tight seal. Ensure that the rubber seal is not twisted and that it sits flat on the body of the pipe. The tapered part of the rubber seal should be pointing in the right direction so that it slots into the main body of the compression joint.
Then, assemble the nut to the fitting body and tighten it to hand-tight, followed by using a wrench to finish tightening. It is important not to over-tighten, as this can deform the sleeve and weaken the seal. A uniform, "line contact" compression around the entire circumference of the ferrule will create the most reliable seal.
To disassemble the compression fitting, simply loosen the compression nut or screw. Remember that compression fittings can only be disassembled and reassembled a few times before the sleeve and/or fitting body should be replaced to ensure a leak-proof seal.
Creating an Airtight Seal with Dense Plastic
You may want to see also
Explore related products
Joining copper and plastic pipes
One method for joining copper and plastic pipes is by using compression fittings. Compression fittings come in various shapes and sizes, including straight reducers, elbows, and T-connections. When using a compression fitting, it is important to ensure that the pipes are clean and free of debris to prevent leaks. The fitting is then assembled by screwing on the nut, followed by the compression ring, and finally, the rubber sealing ring, which must be fitted with the tapered edge facing toward the join.
Another method for joining copper and plastic pipes is by using push-to-connect fittings. These fittings are quick and convenient, requiring no special tools or soldering. With a simple push-and-lock mechanism, a reliable and durable joint can be created between the two pipes.
Transition couplings can also be used to join copper and plastic pipes. These couplings are specifically designed to bridge the gap between different materials using a rubber gasket and stainless-steel clamps to ensure a tight and secure connection. It is important to verify that the pipes are compatible and appropriately sized for the specific system requirements before making any connections.
Plastic compression fittings can be invaluable when trying to join old pipes to new pipes, including odd-sized imperial waste plumbing pipework. They are easy to fit and adjust, and if a connection fails, they can be easily removed and replaced. However, one disadvantage of plastic compression fittings is that they tend to be bulky and may not be suitable for use in tight spaces.
Make Your Glossy Phone Case Dull and Matte
You may want to see also
Explore related products
Using push-fit fittings
Push-fit or push-to-connect fittings are universal pipe fittings that can be installed without the use of special tools. They are also known as push-in or push-fit connectors. They are available in several configurations, typically plastic and copper. They are used to securely connect plumbing pipes and are ideal for joining old pipes to new pipes, including odd-sized imperial waste plumbing pipework. Compression fittings are easy to fit and adjust, and if a connection breaks down, they are simple to remove and refit.
A mechanism inside the fitting locks the pipe using pressure inside the plumbing system. There is no need for soldering, crimping, or gluing. Sharkbite is the most popular brand of push-to-connect fittings on the market. They are time-saving, simple to install, and dependable, at least for a short to intermediate amount of time. However, most plumbers still prefer soldering over push-fit fittings as it provides a more secure and permanent connection.
To use a push-fit fitting, first identify the pipe material. PEX, Copper, CPVC, PE-RT, and SDR-9 HDPE pipe are all compatible with most push-to-connect fittings. Cut the pipe squarely, using a cheap plastic pipe cutter to ensure a clean cut without crushing the pipe. Check for scratches or debris on the pipe and remove any sharp edges or burrs on copper pipes with a deburring tool. Failure to correctly deburr the pipe can affect the fitting and produce leaks. Measure and mark on your pipe where you will insert the push-to-connect fitting. Familiarise yourself with the locking mechanism on the fittings as some manufacturers' locking mechanisms can be counterintuitive.
Push-fit fittings typically have an 'O'-ring seal and a metal-toothed grab ring to secure the pipe and produce a watertight seal. The quality of the internal components is equally as crucial as the fitting body. For excellent corrosion resistance, push-fit fittings employ high-grade materials such as the stainless-steel gripper ring.
How to Stick Fiberglass Resin to Plastic Surfaces
You may want to see also
Frequently asked questions
Compression fittings are used to join plastic pipework together. They are available in various shapes and sizes, including reducers, elbows, and T connections. They are ideal for joining old pipes to new pipes, including old lead wastes and odd-sized imperial waste plumbing pipework.
Compression fittings are easy to fit, adjust, remove, and refit. They are also suitable for joining pipes of different sizes and can be used to connect old imperial plumbing fittings to newer metric waste fittings.
Compression fittings tend to be big and bulky, making them unsuitable for tight spaces. It can be challenging to ensure that the rubber washer is not twisted and that the fitting is tightened correctly to prevent leaks.
First, unscrew all the pieces of the compression fitting to understand how they work. When fitting to a pipe, put on the nut first, followed by the compression ring and the rubber sealing ring, ensuring the tapered edge faces toward the join. Then, push up on the fitting so that the tapered edge squeezes onto it. Finally, hand-tighten the fitting and then use a spanner to tighten it further until it is crimped onto the pipe.
