Flaring plastic tubing is a process used in critical fluidic applications for medical diagnostics, DNA sequencing, pharmaceuticals, and many other industries requiring precise, high-performance fluidic systems. To heat flare plastic tubing, you need to ensure the tubing is cut straight and deburred with a file. When flaring the tube, it is important to use lube on the flaring tool and the tube. For a 37-degree single flare, clamp the tube flush in the correct-size fixture, then centre the forming die on the tube. For a 45-degree double flare, clamp the tube in the correct-size fixture and set the depth by aligning the tube with the bubble flare die.
Characteristics and Values
| Characteristics | Values |
|---|---|
| Tool | Tubing flare set, tubing cutter, hacksaw, cutoff wheel, handheld flaring tool, hydraulic flaring tool, Rigid AN flaring tool, 32-tooth saw blade, tubing reamer, flaring tool kit, deburring tool, hand file, step drill bit, pop rivet, screw |
| Material | Plastic, stainless steel, mild steel, PVC, copper, brass, soft steel |
| Process | Cut, chamfer, deburr, flare, bend, anneal, tighten, align, centre, roll, heat |
| Angle | 37-degree, 45-degree |
Explore related products
What You'll Learn
Use a heat gun to evenly heat the plastic tubing
When using a heat gun to evenly heat plastic tubing, there are several important steps to follow. Firstly, it is crucial to select the right type of heat gun for the task. For industrial applications, a gas or electric-powered heat gun, or one that uses a combination of both, is typically recommended. These heat guns often come with a fan tail nozzle that helps evenly distribute heat. If you are using a propane heat gun, ensure proper ventilation to avoid inhaling gas fumes.
Before starting the heating process, it is important to choose the correct size of tubing. The tubing should fit snugly over the item being heated. It is also essential to clean both your hands and the item being covered to prevent any dirt or oils from causing weak spots once the material is heated.
When using the heat gun, keep it moving to ensure even heating. Hold it at a distance where you can observe the plastic reacting to the heat. Adjust the distance as needed to control the amount of heat applied. Start with a low setting on the heat gun to gradually warm up the plastic. Keep an eye on the plastic, and once it starts to soften, stop heating before it reaches the melting point. The ideal temperature range for most heat shrink tubing is between 194°F to 248°F (90°C to 120°C), but always refer to the manufacturer's instructions.
To achieve a smooth and even finish, work slowly and steadily. Avoid rushing the process, as this can lead to uneven heating and potential burning or warping of the plastic. Always prioritize safety when using a heat gun. Never point the heat gun towards yourself or others, and only allow trained professionals to operate the tool, following the manufacturer's guidelines for safe use.
