Measuring corrugated plastic pipe is a simple but important skill to have for plumbing and building projects. The first step is to determine whether you need to measure the outside or inside diameter of the pipe. For plastic pipes, the outside diameter is the relevant measurement, as the pipe needs to fit into a socket. The next step is to take the measurement, using a flexible tape measure or string, and then convert this to the nominal pipe size, which is the size that will be used in stores. This process differs slightly depending on whether you are using the metric system or the inch/imperial system. For metric, the outside diameter is the same as the name of the pipe, while for the inch/imperial system, the name of the pipe is an approximation of the bore of the inside of the pipe.
| Characteristics | Values |
|---|---|
| Measurement method | Use a tape measure, ruler, or flexible measuring tape across the pipe's width to determine the size. |
| Diameter type | Measure the outside diameter of the pipe, not the inside diameter. |
| Unit conversion | Convert the measurement to the "nominal" pipe size, which is what the pipe will be called in the store. |
| Nominal size calculation | Divide the circumference by pi (approximately 3.14159). |
| Nominal size threshold | Convert if the diameter is smaller than 14 inches (360 mm); no need to convert if it's 14 inches or more. |
| Unit system | Use inches (imperial) or millimetres (metric). |
| Metric system usage | Europe, UK, and other parts of the world. |
| Imperial system usage | North America, Asia, and UK. |
| Pipe length | Custom lengths are available. |
| Pipe thickness | Ranges from 18 gauge to 8 gauge. |
| Pipe diameter | Typically ranges from 12 inches to 144 inches, with variations depending on the specific type and application. |
Explore related products
What You'll Learn
Measure the outside diameter
To measure the outside diameter of a corrugated plastic pipe, you can use a ruler, a soft tape measure, or a caliper. You can also use string if you don't have access to these tools.
First, measure the pipe's circumference by wrapping a soft tape measure around its outside. If you don't have a soft measuring tape, you can wrap a piece of string around the pipe, mark the end point, and then measure the length of the string with a ruler.
Next, divide the circumference by pi (approximately 3.14159) to get the outside diameter. For example, if the circumference is 12.57 inches (319 mm), you would divide by pi and get an outside diameter of about 4 inches (100 mm).
It's important to note that the outside diameter of a pipe is different from its nominal size, which is the size sold in hardware stores. The nominal size of a pipe is based on its inner diameter, which may vary depending on the thickness of the pipe walls. However, the outside diameter always remains the same, even if the pipe wall changes.
Additionally, it's worth mentioning that there are two main systems for labelling pipe diameters: the metric system and the inch/imperial system. The metric system is used in Europe and many other parts of the world, and it labels pipe diameters in millimetres. On the other hand, the inch/imperial system is used in North America and Asia, and it labels pipe diameters in inches. Knowing the difference between these two systems is crucial, as they are not interchangeable.
