Smoking Headlamps: Plastic Points Technique

how to smoke headlamp qith plastic points

Smoking your headlights is a popular vehicle modification that can improve the appearance of your car and give it a unique look. This modification can be done using tint film or spray paint, and it can be reversed by simply peeling off the tint film or using a plastic polish on the spray paint. Before applying the tint or paint, it is important to clean the headlights and remove any dirt, rust, or residue. This can be done using soapy water or a headlight cleaner. After cleaning, you can apply the tint film or spray paint, ensuring that you follow the instructions specific to the product you are using. It is important to note that you should check the rules of the road before driving with smoked headlights, as there may be restrictions or regulations in your area.

Characteristics and Values Table for Smoking Headlamps with Plastic Points

Characteristics Values
Tools Cutter knife, Masking tape, Flat screwdriver, Sealant for rigid plastic or headlights, P240 or finer grid sandpaper, Heat gun or hair dryer, Cloth, Toothbrush, Wrapping film, Gloves
Step 1 Remove bulbs from the headlight unit. Wrap screwdriver with tape and cloth to avoid scratching the lens. Use a heat gun or hair dryer to heat around the edges and slowly slide the screwdriver into the gap to pry it open.
Step 2 Paint the fascia. Sand off the chrome with sandpaper so that paint sticks better. Wash the fascia with soapy water and dry before painting. Spray paint layer by layer, waiting for each layer to dry before adding another.
Step 3 Clean the lens with soapy water and a toothbrush. Dry with a cloth and wrap with film to avoid dust.
Benefits Improved appearance, Variety of colour options, Reduced brightness and glare, Protection from scratches, fogginess, and yellowing.
Tint Film Easier for beginners, can be easily removed and redone, acts as a protective film, can be applied directly without dismantling the assembly.
Spray Paint Cleaner and more elegant look, spray from a distance of 18 inches to 2 feet, move the can in a single motion without lingering on one spot.

shunpoly

Cleaning the headlamp

Before you begin the process of smoking your headlamps, it is important to clean the lens. The lens is likely to be dirty, so it is recommended to wash it with soapy water and a toothbrush to reach the edges. After washing, dry the lens with a cloth, ensuring no watermarks are left behind. You can then wrap the lens with film to prevent dust from settling.

Toothpaste is an effective cleanser for headlamps. It contains abrasive elements that can remove the yellow film from old headlights without scratching the plastic coating. Simply apply a generous amount of toothpaste to the lens and work it around the surface with a brush in a circular motion. Then, buff away any residual toothpaste with a clean rag or towel.

Baking soda is another option. Mix it with a small amount of water to make a thick paste, and apply it to the lens. Leave it for a few minutes, then gently work it around the surface with a brush in a circular motion. You can also mix baking soda with lemon juice and rub it directly onto the headlamp. However, be cautious as lemon juice can damage the paint if left to dry.

For a more straightforward approach, you can purchase a "headlight restoration kit" or a "headlight lens restoration" product from auto supply stores. These products are specifically designed to clean headlight lenses affected by UV exposure.

shunpoly

Removing the bulbs

To begin the process of smoking your headlamps, you will first need to remove the bulbs from the headlight unit. This is a delicate process, so it is important to take your time and be patient.

Start by gathering your tools. You will need a flat screwdriver, some masking tape, and a cloth. Wrap the screwdriver with the tape and cloth to avoid scratching the lens as you work.

If your headlights have sharp edges, start there, as the smaller section will be easier to pry open. Using a heat gun or hair dryer, apply heat around the edge. As you do this, gently slide the screwdriver into the gap and carefully pry it open. Work slowly and gently to avoid damaging the headlight unit.

Once the bulbs are removed, you can continue with the next steps of the process, such as painting the fascia and cleaning the lens. These steps will vary depending on the specific method you choose for smoking your headlamps, whether that be using tints, sprays, or other methods.

It is important to note that smoking your headlights can impact their performance and legality. Smoked headlights reduce glare and reflections, which can be beneficial in certain conditions. However, they may also reduce the brightness of your headlights, so it is important to consider this trade-off and ensure that your vehicle remains road legal.

shunpoly

Sanding the fascia

Before starting the sanding process, it is essential to gather the necessary tools and materials. These include various grit levels of sandpaper, such as 800, 1000, and 2000 grit, as well as a flexible hand sanding backing pad, shop towels, and a spray bottle with water and a few drops of soap. The area around the headlights should be taped up to protect the surrounding paint.

When sanding the fascia, it is important to work in one direction to ensure consistent lines and an even finish. Start with a lower grit sandpaper, such as 800, and spray both the sandpaper and the headlight with water to keep the surface lubricated. Slowly sand the entire headlight, including all edges and corners, until you achieve a uniform surface with fine scratches.

After completing the initial sanding with 800 grit, move on to a finer grit sandpaper, such as 1000. Continue sanding in one direction, keeping the headlight lubricated, until you achieve a uniform finish. You may notice a slight improvement in the clarity of the headlight at this stage. Wipe off the water and repeat the process with an even finer grit, such as 2000. Spending more time on this final step will yield better results.

Once you have finished sanding with the highest grit sandpaper, it is important to clean and polish the headlight to remove any sanding debris and restore clarity. Use soap and water to wipe down the surface, and then apply a polishing compound with a flannel polishing cloth. Alternatively, power tools such as a cotton buffing wheel or felt roloc polishing pads can be used for buffing and polishing.

shunpoly

Applying the tint

There are two main ways to smoke your headlamps: using a tint film or spray paint.

If you're a beginner, tint film is recommended as it can be easily removed if you make a mistake. Tint film also acts as a protective layer over the headlamp, preventing scratches and yellowing. Before applying the film, ensure your headlamps are clean and free of dirt and residue. Spritz your headlights with Windex or soapy water and gently wipe away any dirt, rust, or bugs.

If you're opting for spray paint, it's important to note that this method is irreversible. Make sure to mask off the surrounding areas to avoid getting paint on them. Use a headlight-specific plastic spray paint and spray from a distance of about 18 inches to 2 feet. Move the can in a single motion, either around the headlight or from side to side, ensuring you don't linger in one spot. Start with a very thin coat and let it dry for 10 to 15 minutes. If you want a darker colour, add a second coat using the same spraying method.

For both methods, it's crucial to work patiently and carefully. Taking your time will ensure a better final result.

shunpoly

Spraying the colour

Before you start spraying the colour, make sure you are in a well-ventilated area. You should also wear gloves to avoid getting fingerprints on the paint.

First, you need to sand off the chrome from the fascia with sandpaper so that the paint will stick to the bare plastic surface. Take your time with this step, and don't rush. Wash the fascia with soapy water and dry it properly before you start painting.

You can choose any colour of spray paint you want. Spray the paint layer by layer, and wait for the first layer to dry before applying the second. Don't be overzealous with the paint to avoid an "eye drop effect" on the fascia.

After painting, clean the lens with soapy water, using a toothbrush to reach the edges. Dry the lens with a cloth, being careful not to leave any watermarks. Then, wrap the lens with wrapping film to prevent dust or dirt from settling on it.

Finally, use a sealant to create a tight seal between the housing and the clear lens. You can use RTV silicone or a headlight restoration kit that includes a clear coat spray paint.

Frequently asked questions

You will need a cutter knife, masking tape, a flat screwdriver, sealant for rigid plastic or headlights, P240 or finer-grit sandpaper, a heat gun or hair dryer, cloth, a toothbrush, wrapping film, gloves, and plenty of time and patience.

First, remove all the bulbs from the headlight unit. Then, wrap your flat screwdriver with masking tape and cloth to avoid scratching the lens. Heat the edges and slowly slide the screwdriver into the gap to pry it open. Next, sand off the chrome with sandpaper so that the paint will stick better. Wash the fascia with soapy water and dry it before painting. Spray the headlight with a headlight-specific plastic spray paint. Don't linger on one spot and start with a thin coat. Let the paint dry before adding another coat if necessary. Finally, clean the lens with soapy water and dry it before wrapping it with film.

Smoked headlights improve the appearance of your vehicle and make it stand out. They also lower the brightness and glare of your headlights, which can be uncomfortable for other drivers. Additionally, the tint acts as a protective film, preventing the headlamps from yellowing and scratching.

Yes, if you use a tint film, you can simply peel it away and reverse the effect. However, if you use spray paint, it is irreversible.
