Plastic section modulus is a geometric property of a given cross-section used in the design of beams or flexural members. It is used to calculate a cross-section's capacity to resist bending after yielding has occurred across the entire section. The plastic section modulus depends on the location of the plastic neutral axis (PNA) and is defined as the sum of all elemental areas above or below the centroid of the cross section multiplied by the distance from each of the individual elemental centroids to the centroid of the cross section as a whole. The plastic section modulus is used for materials where irreversible plastic behaviour is dominant, and it is larger than the elastic section modulus, reflecting the section's strength beyond the elastic range.
| Characteristics | Values |
|---|---|
| Use | Used to calculate a cross-section's capacity to resist bending after yielding has occurred across the entire section |
| Application | Used for materials and structures where limited plastic deformation is acceptable |
| Plastic Neutral Axis (PNA) | Depends on the location of the PNA, which is defined as the axis that splits the cross-section such that the compression force from the area in compression equals the tension force from the area in tension |
| Calculation | Calculated as the sum of the areas of the cross-section on each side of the PNA (which may or may not be equal) multiplied by the distance from the local centroids of the two areas to the PNA |
| Plastic Moment | Reached when the strain at a cross-section is of sufficient magnitude so that virtually the entire section has yielded |
| Plastic Moment Calculation | Requires knowledge of the compressive and tensile strength of the respective material |
| Equation | If the shape factor f is known, then Z=S*f; otherwise, it must be derived for each specific cross-section |
Explore related products
What You'll Learn
Calculating plastic section modulus for basic shapes
The plastic section modulus is used to calculate a cross-section's capacity to resist bending after yielding has occurred across the entire section. It is used for materials and structures where limited plastic deformation is acceptable and is larger than the elastic section modulus.
The plastic section modulus depends on the location of the plastic neutral axis (PNA). The PNA is defined as the axis that splits the cross-section such that the compression force from the area in compression equals the tension force from the area in tension. For sections with constant yielding stress, the area above and below the PNA will be equal, but for composite sections, this is not necessarily the case.
The plastic section modulus is calculated as the sum of the areas of the cross-section on each side of the PNA (which may or may not be equal) multiplied by the distance from the local centroids of the two areas to the PNA. This can be represented by the formula Z=S*f, where Z is the plastic section modulus, S is the elastic section modulus, and f is the shape factor.
For a rectangle with width b and height h, the plastic section modulus can be calculated as follows:
- First, find the area of one half of the rectangle: bh/2.
- Next, determine the distance between the centroids of the half areas, which is h/2.
- Finally, multiply the area and distance together to get bh^2 /4 as the plastic section modulus for a rectangle.
For other basic shapes, such as circles and triangles, similar calculations can be performed using the relevant formulas and dimensions. These formulas can be found in tables and resources specific to structural engineering and mechanics.
