Designing products in plastic requires a good understanding of the capabilities of each production method and the properties of each plastic type. Injection moulding is the most common and versatile method of manufacturing plastic products, but other methods include cutting, extrusion, and 3D printing. The design process must consider factors such as circularity, efficiency, cost, and safety regulations. For example, the wall thickness of a plastic product will depend on its size and the external forces it will endure. The complexity, reliability, and accuracy of the design will also impact the workload for product structural design, requiring superb technical and engineering abilities from designers.
| Characteristics | Values |
|---|---|
| Design stage | Tooling concepts, injection molding, safety, functionality, performance, manufacturability, cost efficiency, and aesthetics |
| Injection molding | Melting plastic granules, injecting a predefined amount of melt into the mold, and cooling and solidifying the plastic |
| Tooling | Two mold halves that form a cavity to define the final part's shape |
| Prototyping | 2-D prints, 3-D models, and physical prototypes for evaluation |
| Wall thickness | 2.4-3.2mm for large components, 1.0mm for smaller components, with reinforcing ribs to increase strength |
| Hole depth | About two times the diameter of the core pin for small pins, four times for larger pins |
| Hole spacing | At least two times the thickness of the part or the diameter of the core pin |
| Draft angle | Minimum of 1 degree per side, preferably between 2 and 5 degrees per side, to assist in part ejection and improve productivity |
| Ribs | Used for strengthening and decoration, with a minimum base radius to reduce stress and improve flow and cooling |
| Bosses | Basic design element used for assembly, mounting, location, or reinforcement |
| Inserts | Used as fasteners or support elements, typically made of metal with specific shapes, strength, and bonding to the plastic matrix |
| Raw materials | Plastic resin pellets |
