Plastic bumper covers are an essential component of modern automobiles. They are typically made from flexible plastics like polyethylene or polypropylene and serve as a protective layer over the main bumper, enhancing shock absorption and minimising damage during low-velocity impacts. These covers are designed to be impact-resistant and can often withstand collisions with minor cosmetic damage. Repairs to plastic bumper covers can be made using a range of techniques, including grinding, sanding, sculpting, and painting, although overheating the plastic can impair its functionality. While plastic bumper covers are not moving parts, they can break or become damaged and may need replacement.
| Characteristics | Values |
|---|---|
| Purpose | To provide a finished appearance to the car and protect the metal bumper underneath |
| Composition | Plastic or a plastic-rubber material |
| Types | Urethane, Polyethylene, Polypropylene, Polyester, Polycarbonate, Acrylonitrile Butadiene Styrene, Polyamide, Polybutylene Terephthalate, Polyvinyl Chloride, Polystyrene, Polyacetal, Polyphenylene Oxide |
| Repair | Grinding, sanding, sculpting, and painting |
| Cost | Repairing a dented bumper costs several hundred dollars, while replacing the entire bumper costs around $900 |
Explore related products
What You'll Learn
Plastic bumper repair
A plastic bumper cover is a trim piece that forms part of the bumper. It attaches to the main bumper cover and the underbody of the car. It is usually made from a soft, flexible plastic.
Begin by scuffing the damaged area and cleaning it with plastic surface cleaner. If the bumper is cut or torn through completely, scrub the inner and outer surfaces, rinse, and let the surface dry. Then, wipe the area with prep solvent, moving in only one direction. After the solvent has dried, sand the area by hand with 80-grit paper. Form a "V" groove in the damaged area on the front and back sides of the fascia. This allows for better alignment of the two edges and provides more surface area for the repair material to adhere to. For plastic types that powder when sanded (PUR, TPUR), cut the grooves with a 24-grit disc on a sander. For plastics that smear when sanded (PP, PPO, TPE), make the grooves using a cordless drill and a rotary file. Repair tears and cuts from the back side of the fascia. If the cut or tear is large, you may need to align and then hold the edges of the repair with masking tape on the front of the fascia.
Once the repair is completed, apply two wet coats of flexible part sealer. After drying for 30 minutes, the fascia is ready for priming and painting. Prime the fender with two coats of any two-part primer-surfacer, allowing the primer to dry between coats. Once the primer has hardened, dry sand the repaired areas with 400-grit paper to level it and remove any imperfections. Before spraying the bumper with basecoat, wetsand it and gently wipe the area with a tack rag to remove dust. Then, spray according to the manufacturer's instructions. You may need to repeat this process two or three times to cover completely. Once the base coat is dry (usually about 30 minutes), mix the clearcoat with hardener. Apply two medium clearcoats, allowing each to dry in between.
Protecting High Plastic Fences from Strong Winds
You may want to see also
Explore related products
Plastic bumper replacement
Plastic bumper covers are exterior parts of a vehicle that are designed to absorb impact and protect the rest of the vehicle from damage. They are usually made from semi-flexible plastic, which can easily rip, bend, or break in the event of a collision.
If your plastic bumper is damaged, you have several options for repair or replacement. Minor issues such as scratches, dents, and chips can often be repaired using specialised tools found in an auto body shop. The shop will also repaint or blend any repaired areas to match the rest of the vehicle.
However, if the damage is severe, such as deep cracks, holes, or if the bumper is falling off the vehicle, a bumper replacement is recommended. New technologies have made more repairs possible, so it is best to have your bumper evaluated by a professional to determine the best course of action.
If you choose to repair your plastic bumper, the process typically involves grinding, sanding, sculpting, and painting. Here is a step-by-step guide to repairing a plastic bumper:
- Remove the plastic piece from your bumper. The screws connecting the plastic covering can usually be found under the tail lights, behind the wheel wells, or below the trunk latch.
- Find a stamp on the inside of your bumper labelling it as PP, PPO, TPE, PUR, or TPUR. This will help you determine the right adhesives and repair products for your bumper's plastic type.
- Slightly scuff the damaged area and clean it with a plastic surface cleaner.
- If the bumper is cut or torn completely, scrub the inner and outer surfaces, rinse, and let the surface dry.
- Wipe the area with prep solvent, moving in only one direction. Once it's dry, sand the area by hand with 80-grit paper.
- Form a "V" groove in the damaged area on the front and back sides of the fascia to align the edges easily and provide more surface area for the repair material to adhere to.
- Repair tears and cuts from the back side of the fascia, using masking tape on the front if needed to hold the edges of the repair.
- Apply two wet coats of flexible part sealer and let it dry for 30 minutes.
- Prime the fender with two coats of a two-part primer-surfacer, letting it dry between coats.
- Once the primer has hardened, dry sand the repaired areas with 400-grit paper to level it and remove any imperfections.
- Before spraying the bumper with basecoat, wetsand it and gently wipe the area with a tack rag to remove dust. Then, spray according to the manufacturer's instructions. You may need to repeat this process a few times to completely cover the area.
- Once the base coat is dry, mix the clearcoat with hardener and apply two medium clearcoats, allowing each to dry in between.
The cost of repairing a rear bumper dent typically ranges from $150 to $600, while the cost of replacing a bumper will depend on various factors such as the extent of the damage, the type of vehicle, and your location.
Creating Plastic Product Prototypes: A Step-by-Step Guide
You may want to see also
Explore related products
$171.45 $189.84
Plastic bumper function
A plastic bumper is a basic safety component in a vehicle. Bumpers are designed to absorb impact in a collision, minimising repair costs and protecting pedestrians from injury. They are attached to or integrated with the front and rear ends of a motor vehicle.
The first bumpers, installed in 1897, were made of metal and served solely aesthetic purposes. Over time, bumpers evolved to include a functional purpose, with the first bumper designed to absorb impact appearing in 1901. This was made of rubber, and Frederick Simms gained a patent in 1905. Automakers added bumpers in the mid-1910s, but these consisted of a strip of steel across the front and back of the vehicle.
In the 1970s, Renault became the first company to equip its popular R5 model with a plastic bumper. In the 1980s, plastics solidified their position as the main protective component in vehicles. Today, bumpers are made from expanded polypropylene (EPP), which reduces weight and improves the safety of cars.
Modern bumpers are designed to be larger to fit fog lights, air intake grates, and parking sensors. They are also made of flexible materials, such as foams and crushable plastics, to reduce the severity of impact on legs. Lower bumper covers, in particular, are made from soft, flexible plastic and help guide air through the radiator.
Plastic Waterproofing: Cold Weather Protection
You may want to see also
Explore related products
Plastic bumper design
In the 1960s, bumpers became lighter and more decorative, with chrome-plated, blade-like designs accompanied by a painted metal valance. During this decade, multi-piece construction became the norm, integrating grilles, lighting, and rear exhaust into the bumpers. General Motors introduced an innovative "Endura" body-coloured plastic front bumper for the 1968 Pontiac GTO, which could withstand low-speed impacts without permanent deformation. Similar elastomeric bumpers were featured on the 1970-71 Plymouth Barracuda. Renault also introduced a plastic bumper made of sheet-moulding compound on the Renault 5 in 1971.
Today, the standard design for bumpers on modern automobiles includes a plastic cover over a reinforcement bar made of steel, aluminium, fibreglass composite, or plastic. The plastic cover is typically made of polycarbonate (PC) and acrylonitrile butadiene styrene (ABS), known as PC/ABS. This combination provides good impact strength and weather resistance. Bumpers are designed to protect vehicle components during collisions by dissipating the kinetic energy generated by the impact.
Lower bumper covers, made of soft, flexible plastic, are also an important component of bumper design. They attach to the main bumper cover and the underbody of the car, helping to guide air through the radiator. Additionally, modern bumper designs are being optimised to mitigate injury to pedestrians, incorporating softer materials such as foams and crushable plastics to reduce the severity of impact.
Plastic bumper repairs involve processes such as grinding, sanding, sculpting, and painting. Vacuum forming is a common method used in the production of plastic bumpers, allowing for precise engineering and a perfect fit for specific vehicle models.
Transforming Plastic Dolls into Antique Treasures
You may want to see also
Explore related products
Plastic bumper maintenance
Plastic bumper covers are trim pieces that form part of the bumper. They are usually made from soft, flexible plastic and are attached to the main bumper cover and the underbody of the car. Although they are not moving parts, they can still break or get damaged.
Scrub, Rinse and Sand
If your bumper is cut or torn, scrub the inner and outer surfaces. Rinse and let the surface dry, then sand the area by hand with 80-grit paper.
Create a "V" Groove
In the damaged area, form a "V" groove on the front and back sides of the fascia. This will make it easier to align the two edges and provide more surface area for the repair material to adhere to.
Choose the Right Adhesive
The type of adhesive you need will depend on the type of plastic in your bumper. Look for a stamp on the inside of your bumper labelling it as PP, PPO, TPE, PUR, or TPUR. Consult with a professional at an auto parts store to determine the right adhesive for your bumper's plastic.
Apply a Flexible Part Sealer
Once your repair is complete, apply two wet coats of flexible part sealer. After 30 minutes of drying time, the fascia is ready for priming and painting.
Prime and Paint
Prime the fender with two coats of a two-part primer-surfacer, letting it dry between coats. After the primer has hardened, dry sand the repaired areas with 400-grit paper to smooth it and remove any imperfections. Before spraying the bumper with basecoat, wetsand it and gently wipe the area with a tack rag to remove dust. Then, spray according to the manufacturer's instructions.
Apply a Clearcoat
Once the basecoat is dry, mix the clearcoat with hardener and apply two medium clearcoats, allowing each to dry in between.
By following these steps, you can maintain and repair your plastic bumper cover, keeping your car looking its best and protecting it from further damage.
Revamping Old Plastic Chairs: Creative Makeover Ideas
You may want to see also
Frequently asked questions
Plastic bumper covers are made from semi-flexible plastic and are used to cover the metal bumper of a car. They are designed to absorb shock or impact at low velocity and protect the car from minor abrasions.
A lower bumper cover is a trim piece that forms part of the bumper. It attaches to the main bumper cover and to the underbody of the car.
A bumper is a structural component that is designed to absorb the impact in a collision and protect the car and its passengers. Modern bumpers are made with a combination of materials, including plastic, steel, aluminium, and an impact-absorbing spring device.
Repairing a plastic bumper involves grinding, sanding, sculpting, and painting. If the bumper is cut or torn, the inner and outer surfaces must be scrubbed and sanded. The damaged area must then be heated and smoothed out, and new material may need to be welded on.
The cost of repairing a plastic bumper depends on the extent of the damage. A typical dented bumper will cost a few hundred dollars to repair, while replacing the bumper entirely can cost around $900.
