A plastic triangle is a tool used in engineering and technical drawing to help create straight lines and accurate angles. It is a triangular piece of transparent plastic with the possibility of ruler and protractor markings. They are also known as set squares and come in two common forms, both right triangles: one with 90-45-45-degree angles and the other with 30-60-90-degree angles. They are economical and useful for students, but care must be taken to avoid warping or damaging the tips.
| Characteristics | Values |
|---|---|
| Material | Transparent plastic |
| Other materials used | Polished wood |
| Uses | Engineering and technical drawing |
| Function | Provides a straightedge at a right angle or other particular planar angle to a baseline |
| Common features | Markings of a ruler and a half-circle protractor |
| Outer edge | Bevelled |
| Common forms | Right triangles with angles of 90-45-45 degrees and 30-60-90 degrees |
| Combinations | Two forms can be combined to yield 15° and 75° angles |
| Sold with | Protractors and compasses |
| Variants | Larger sizes, fixed or detachable handles, with or without bevelled edges, with or without ink nodules or embossed labels |
| Markings | Extra markings at angles of 7° and 42° (138° and 173°) |
| Damage prevention | Lay flat or hang when not in use to prevent warping or chipping |
Explore related products
What You'll Learn
Uses: Engineering and technical drawing
A plastic triangle, also known as a set square, is a tool used in engineering and technical drawing. It is a triangular piece of transparent plastic with the centre removed to provide a straight edge at a right angle or other specific planar angle to a baseline.
The simplest form of a set square is a right triangle with either 90-45-45 degree angles or 30-60-90 degree angles. The outer edges are typically bevelled. These set squares often have markings similar to a ruler and a half-circle protractor. Combining the two usual forms by placing their hypotenuses together yields 15° and 75° angles. They are often sold in packs with protractors and compasses.
An adjustable set square is less common. It is made by cutting the body of the triangle in half and rejoining it with a hinge marked with angles. Some variants have extra markings at angles of 7° and 42° (138° and 173°) in addition to the normal 45° and 90° markings to ease dimetric axonometry. Other variants feature angle scales in gons instead of degrees.
When not in use, it is important to lay plastic triangles flat or hang them up to prevent warping or chipping. If a triangle is dropped and the tip is damaged, a sharp knife can be used to cut off the affected part. If the triangle is warped, one can try to bend it back by hand or leave it lying on a flat surface with weights on it. If the triangle becomes permanently warped, it will need to be replaced. To test the straightness of a triangle, place it against a T-square and draw a vertical line. Then, reverse the triangle and draw another line along the same edge. If the triangle is straight, the two lines will coincide.
