Compression fittings are used to connect metal or plastic pipes and tubing. They are commonly used in plumbing, gas installations, and hydraulic equipment. They are also used in medical devices, chromatography, bomb detection instruments, and inkjet printing. Compression fittings are versatile and can be used with a variety of tubing types, including PVC, PEX, and PE. The type of tubing used depends on the specific requirements of the application, such as rigidity, durability, flexibility, and pressure resistance. It is important to match the tubing diameter with the fitting size to ensure a secure and leak-free connection. Proper preparation, cutting, alignment, and testing are crucial for a successful installation.
Explore related products
What You'll Learn
Compression fitting types: brass, steel, or plastic inserts
Compression fittings are used in plumbing systems to join pipes and tubing. They are also used in gas installations and hydraulic equipment. These fittings typically consist of three pieces and are usually made from brass, steel, or plastic. Brass compression fittings, for example, are often used in plumbing projects and come in the form of a brass ring, or "olive", that is compressed between a nut and the fitting when the nut is tightened. Steel compression fittings are also available and are known to be stronger than plastic pipes. Plastic compression fittings are also available and are often used for DIY projects as they do not require soldering or heat to apply.
Brass compression fittings are typically used to join copper or plastic pipes and tubing. The process of joining pipes with brass fittings involves screwing the fitting's tapered insert onto the end of one length of pipe, sliding the brass ring over the first length of pipe, and then tightening the nut over the threaded head of the fitting with a spanner. This compresses the brass ring between the nut and the fitting, creating a tight grip on the pipe.
Steel compression fittings are also commonly used, especially for joining stronger materials like copper or steel pipes. Similar to brass fittings, steel fittings involve screwing a tapered insert onto the end of one pipe, followed by tightening a nut with a spanner to secure the connection. Steel fittings provide a strong and secure joint, making them suitable for applications that require high strength and durability.
Plastic compression fittings, on the other hand, are often used for joining plastic pipes and tubing in DIY projects. Plastic fittings usually come with plastic inserts that reinforce the pipes and help maintain their circular shape, making the connection easier. Similar to brass and steel fittings, plastic fittings also involve tightening a nut to compress the fitting onto the pipe. Plastic fittings are known for their ease of use and do not require specialised tools or techniques such as soldering or applying heat.
Compression fittings come in various types, including elbow joints, tee fittings, couplers, and union fittings. Elbow joints are angular fittings that change the direction of pipes, commonly by 45 or 90 degrees. Tee fittings have a T shape with two inputs or outputs opposite each other and a third input or output at a 90-degree angle. Couplers are designed to create permanent joints, while union fittings offer flexibility and can be repositioned or moved when needed.
