Creating A Custom Plastic Mold: Understanding The Cost Factors

Injection molding is a process that can be used to produce a good-looking product quickly and at volume. The cost of creating a mold depends on several factors, including the required production volume, the complexity of the part design, the mold material, and the process used to create the mold. Simple low-volume 3D-printed molds can be produced for as little as $100, while the cost of more complex molds for high-volume production can reach $100,000 or more. It's important to consider the number of parts being produced, as higher production numbers will lower the final per-piece cost. The majority of the cost for plastic injection molding will be the machining of the injection mold.

Cost of plastic injection moulding

The cost of plastic injection moulding varies depending on several factors, including the required production volume, the complexity of the part design, the type of material used, and the process used to create the mould.

Simple low-volume 3D-printed moulds can be produced for as little as $100, while the cost of designing and manufacturing complex moulds for high-volume production can exceed $100,000. The cost of purchasing materials for moulds also differs according to the material chosen. Thermoplastic pellets, for example, cost approximately $1 to $5 per kg, while the cost of plastic resins ranges from $2 to $20 per pound.

The number of injection cavities in the mould is another factor that affects cost. High-production moulds, also known as multi-cavity moulds, have multiple identical injection cavities, allowing for the production of the same part or related parts in a single pressing. Family moulds, on the other hand, have two or more similar but not necessarily identical cavities. These moulds are typically used for producing parts that snap together, such as the right and left sides of an object.

The cost of plastic injection moulding can also depend on whether the mould is being produced in-house or outsourced. For enterprises with the necessary equipment and technical know-how, creating moulds in-house may be the least expensive option. However, if the required tools are not readily available, outsourcing can reduce the costs associated with developing a mould.

Additionally, the complexity of the part design can significantly impact the cost of plastic injection moulding. Simple, small, and single-cavity plastic injection moulds typically cost between $1,000 and $5,000, while very large or complex moulds can cost $80,000 or more. On average, a typical mould that produces a relatively simple, small part costs around $12,000.

It is important to note that the price of the mould is just the beginning. Other factors that contribute to the overall cost of a plastic injection moulding project include raw materials, operation, and potential repair costs. While the upfront costs for injection moulding can be significant, it is a fast and economical way to produce large quantities of plastic parts, as the cost per part decreases with higher production volumes.

Cost of outsourcing mould-making

Outsourcing mould-making can be a highly reliable turnkey solution for plastic injection-moulded part production. It allows companies to take advantage of extensive processes and resources, such as cutting-edge equipment and highly skilled, experienced staff.

The cost of outsourcing mould-making can vary depending on several factors, including the part size, complexity, material, and anticipated quantities. For instance, a single cavity mould that produces 1,000 washers per year may cost around $1,000 to $2,000, while a 12-cavity hardened "family" mould that produces 100,000 Xbox controllers per month could cost $60,000 to $80,000 or more.

The design fee for a mould typically ranges from $100 to $300 but can be higher for more complex or larger moulds. The machining process is usually the most expensive part of mould-making, with the cost depending on the type and grade of equipment used. The hourly rate for top brand equipment can be two to three times higher than that of ordinary equipment.

Additionally, the cost of purchasing materials for moulds can vary depending on the chosen material. Thermoplastic pellets, for example, cost approximately $1 to $5 per kg. It's important to consider the design, material, and amount of material used when determining the total material cost.

When outsourcing mould-making, it's essential to consider all the factors that can impact the final cost. These include the production volume, the complexity of the part design, and the process used to create the mould. By providing detailed information and specifications to the mould manufacturer, you can receive accurate quotes and ensure a successful mould-making project.

Cost of designing a mould

The cost of designing a mould depends on several factors, including the required production volume, the complexity of the part design, the material used, and the process used to create the mould.

Simple low-volume 3D-printed moulds can be produced for as little as $100, while the cost of designing and manufacturing complex moulds for high-volume production can reach $100,000. The cost of purchasing materials for moulds varies depending on the chosen material. Thermoplastic pellets, for example, cost approximately $1 to $5 per kg. The cost of materials is influenced by the design of the model, the chosen material, and the amount of material required for the injection moulding process.

The number of injection cavities in a mould can also impact the final cost. High-production moulds, also known as multi-cavity moulds, have multiple identical injection cavities, increasing production efficiency. Family moulds, on the other hand, have two or more similar but not necessarily identical cavities, resulting in the production of related parts in a single pressing.

It is recommended to have a target price in mind before designing a mould, as this can influence the planning and execution of the project. Outsourcing mould-making overseas may be a more cost-effective option, but it is important to consider the factors involved in bringing the mould to optimum production standards.

Additionally, the cost of equipment is a factor to consider. Purchasing a desktop injection moulding machine and an SLA 3D printer can cost less than $10,000, making it a more affordable option for businesses starting with injection moulding.

Overall, the cost of designing a mould can vary significantly, ranging from a few hundred dollars to over $100,000, depending on the specific requirements and factors involved.

Cost of purchasing materials for moulds

The cost of purchasing materials for moulds depends on several factors. These include the required production volume, the complexity of the part design, the material used, and the process used to create the mould.

Simple low-volume 3D-printed moulds can be produced on an SLA resin 3D printer for as little as $100. An aluminium mould for a mid-volume production run of approximately 1,000-5,000 units falls within the range of $2,000 to $5,000. For moulds with more complex geometries and larger production runs of approximately 10,000+ units, the cost of the mould can range from $5,000 to $100,000.

The cost of purchasing materials for moulds also differs according to the material chosen. Thermoplastic pellets, for example, cost approximately $1 to $5 per kg. Material cost is defined by a model's design, the chosen material, and the amount of material used in the injection moulding process.

The number of injection cavities in a mould is another factor that affects cost. High-production moulds can have multiple identical injection cavities, which are known as multi-cavity moulds. Family moulds, on the other hand, have two or more similar cavities that are not necessarily identical. These moulds will have multiple cavities that will produce the same or related parts in one pressing, increasing production efficiency.

The cost of the mould should be weighed against the number of parts being produced. Higher production numbers will lower the final per-piece cost of each part as the total injection mould cost can be spread out over hundreds or thousands of parts.

Despite the considerable fixed start-up costs, the injection moulding process has low variable costs due to inexpensive thermoplastics materials, short cycle times, and decreasing labour needs due to automation and economies of scale. This means that the variable costs of production are low, and the process becomes more efficient and cost-effective at higher volumes.

Cost of equipment for moulding

The cost of equipment for moulding depends on several factors, including the type of equipment, the production volume, the complexity of the design, the material used, and the process used to create the mould.

Type of Equipment

The type of equipment used for moulding can vary, from simple desktop injection moulding machines to more complex hybrid machines that combine electric and hydraulic technologies. The cost of purchasing a desktop injection moulding machine and an SLA 3D printer can be less than $10,000, while hybrid machines require a large amount of start-up capital and high maintenance costs.

Production Volume

The number of items to be produced using injection moulding will determine the production technology and the quality of material used when creating the mould. Low-volume production of 100 to a couple of thousand units can be achieved with simple 3D printed moulds, which can cost as little as $100. Mid-volume production of 1,000 to 5,000 units can range from $2,000 to $5,000, while high-volume production of 10,000+ units can cost anywhere from $5,000 to $100,000.

Complexity of Design

Complex part designs with intricate geometries require complex moulds, which are generally more expensive to fabricate than simpler moulds. The presence of undercuts, for example, may require sliding side-actions and cores, increasing the cost of the mould.

Material Used

The choice of material for the mould can also impact the cost, with steel or aluminium being common options. Steel moulds are more durable and suitable for high-volume production but come with a higher initial cost. Aluminium moulds, on the other hand, can be produced with high accuracy using CNC machining or 3D printing at a lower cost.

Process Used to Create the Mould

Different processes for creating moulds include CNC machining, electric discharge machining (EDM), and 3D printing. CNC machining is well-suited for making metal moulds from aluminium or steel, while EDM is used for creating complex and precise features in metal moulds. 3D printing is a fast and cost-effective option, with simple low-volume 3D printed moulds available for as little as $100.

It is important to note that the cost of equipment for moulding can vary widely depending on the specific requirements and factors involved in the project.
