Welding Plastics: Joining Techniques For Plastic Components

how to add plastic to plastic

There are many types of plastic and many types of glue, and choosing the wrong combination can result in a weak bond or, rarely, damage to the object you are trying to repair. The type of glue you need depends on the type of plastic you are trying to repair. For example, a glue that works great with styrene may only work marginally with PVC. If you know the type of plastic, you can get glues made specifically for it. Different varieties of plastic require different glues, and the recycling symbol can help identify the type of plastic. In general, the most common types of adhesives to glue plastic together are super glue, plastic bonding systems, and epoxy.

shunpoly

Identify the type of plastic

There are several methods to identify the type of plastic. The easiest way is to look for the international code: three arrows forming a triangle with a number in the middle. This number corresponds to the type of plastic. For example, symbol 1 represents polyester and PET plastics, while symbol 2 represents High-Density Polyethylene (HDPE).

Another way to identify plastic is through its appearance and texture. For instance, polyethylene has a smooth and flexible texture, while Low-Density Polyethylene (LDPE) is thin and crumbly. On the other hand, HDPE is tougher to deform and often has a translucent, milky white coating. Polypropylene is also flexible but hard to break and is often used for product containers.

The float test and burn test are also methods to identify plastics, although they may not always be accurate. For example, when exposed to flames, polyethylene burns with blue flames and yellow tips, while PVC plastic produces yellow flames with green tips. However, burning plastic is harmful to health and the environment, so caution should be exercised.

Additionally, some plastics are marked within angle brackets, such as >PC< for polycarbonate and >PA6< for nylon. ABS plastic, for instance, is often marked as >ABS<.

shunpoly

Choose the right adhesive

Choosing the right adhesive for bonding plastic to plastic is crucial, as the wrong combination can result in a weak bond or even damage the object. There are many types of plastics and glues to choose from, and the best method depends on the type of plastic being used.

The first step is to identify the type of plastic you are working with. Different varieties of plastic require different adhesives. The recycling symbol, usually consisting of three arrows forming a triangle, can be very helpful in this regard. For instance, plastics marked with a ''6' or 'PS' are polystyrene, and can be glued with poly cement, or a specialised plastic glue like Loctite Epoxy Plastic Binder or Super Glue Plastic Fusion. On the other hand, plastics marked with a '2', '4', '5', 'HDPE', 'LDPE', 'PP', or 'UMHW' are types of polyethylene or polypropylene, which are much more difficult to glue. Specific products like the Loctite Plastics Bonding System or Scotch Weld DP 8010 are designed for these plastics.

Additionally, some plastics may require a plastic glue that incorporates solvent-based bonding, while others may need an epoxy-based adhesive. For instance, CPVC and PVC can be glued using CPVC plumbing pipe cement or PVC primer and glue, respectively. Polycarbonate can be glued with a solvent, and while super glue can be used, a solvent typically provides a better bond. Hard polyester can be glued with epoxy or super glue, while polypropylene (PP), polyethylene (PE or HDPE), nylon, delrin, and acetal are difficult to glue and may require alternative methods like melting the plastic with a soldering iron or wood-burning iron.

Super glue is a common adhesive that can be used on a wide variety of surfaces and is great for small repairs and quick fixes. However, it is important to check the label to ensure the super glue is compatible with the specific type of plastic being used. Epoxy is another versatile option, forming a very durable material when hardened, and there are epoxy formulas specifically designed for plastics.

In summary, identifying the type of plastic is essential for choosing the right adhesive. While some plastics are more challenging to glue than others, knowing the specific type of plastic will help determine the most suitable adhesive, whether it be super glue, epoxy, specialised plastic glue, or another bonding method.

shunpoly

Prepare the surface

Preparing the surface of plastic for bonding is critical to the success of any adhesive, especially when using super glue. The first step is to identify the type of plastic you are dealing with, as different plastics require different types of glue. For example, plastics in categories 1, 2, 4, and 5 are very difficult to glue, while category 3 (PVC) is commonly used in plumbing and can be glued using a two-part primer and PVC solvent cement. Once you have identified the type of plastic, choose an appropriate adhesive that is compatible.

The next step is to ensure that the plastic surface is clean, dry, and free of any contaminants, such as dirt, dust, or oily residues. This can be achieved by using specialised cleaning sprays, such as soap, isopropyl alcohol, or industrial cleaning sprays. It is important to consider the type of plastic when choosing a cleaning method, as some methods may damage certain types of plastic. For general-purpose plastics, a surface cleaner spray can be effective, while a plastic cleaner spray may be more suitable for more sensitive types of plastic. After cleaning, the plastic surface should be thoroughly dried using a soft, lint-free cloth to avoid any loose fibres that may interfere with the bonding process.

In some cases, roughening the smooth surface of the plastic can improve adhesion. This can be done lightly using sandpaper, especially for plastics like PEEK, nylon, and polycarbonate. However, if the plastic already has a rough surface, this step can be skipped. Additionally, certain adhesives may include an activator as a preliminary step to prepare the surface of the plastic for better adhesion.

Other methods for preparing the surface of plastic for bonding include flame treatment and plasma treatment. Flame treatment involves exposing the surface to a gas flame for a few seconds, which oxidizes the surface and increases surface energy. On the other hand, plasma treatment is typically carried out under partial vacuum, producing excited species that react with the plastic substrate and provide better stability.

shunpoly

Apply the adhesive

When gluing plastic to plastic, it's important to remember that different types of plastics require different types of adhesives. Some common types of adhesives used for gluing plastic to plastic include super glue, plastic bonding systems, and epoxy. Knowing the type of plastic you are working with is key to choosing the right adhesive.

Before applying the adhesive, it is important to prepare the surface of the plastic. Clean the plastic surface with soap or a specialised plastic cleaner, or soak the plastic in isopropyl alcohol. Dry the surface thoroughly. Avoid touching the plastic with bare hands to minimise oil residue. To create a rough surface for the glue to bond to, sand the plastic with 120 to 200 grit sandpaper, or use steel wool or emery cloth. Some special plastic bonding systems include an activator as a preliminary step to prepare the surface of the plastic to accept the adhesive and create a stronger bond. Apply the activator to both surfaces and allow it to dry for about a minute.

Apply a small amount of adhesive to one surface. Super glue tends to go a long way, so just a drop or two is usually enough. Press the surfaces together immediately and hold them still for about 15 to 30 seconds or until a bond begins to form. For two-part epoxies or adhesives, carefully read the product's instructions for blend ratios and mix the components as directed to activate the adhesive. Most epoxies come in a dual-syringe dispenser, making it easy to measure out equal parts of the two components. Dispense the required amount of resin and hardener onto a disposable surface and mix them together.

Once the adhesive is applied, let it dry by waiting at least 10 minutes before moving the combined parts. For maximum strength, leave the plastic undisturbed for 24 hours to allow the bond to cure. Clean up any excess wet adhesive with a damp paper towel. Dried adhesive can be carefully scraped away with a razor blade, and any remaining residue can be removed with acetone.

shunpoly

Allow adequate drying time

When gluing plastic to plastic, it is important to allow adequate drying time for the adhesive. The drying time will vary depending on the type of adhesive used and the type of plastic being bonded. For example, super glue typically dries within a few moments, while plastic glue can take a minute or two to set and up to 30 minutes to fully dry. Epoxy, a two-part system consisting of a resin and hardener, has a required working time once the reaction is initiated by mixing the components.

It is crucial to follow the specific instructions on the adhesive's packaging, as different brands and types of adhesives may have varying drying times. In general, it is recommended to let the glue dry for at least 10 minutes before handling the bonded parts. For the best results and optimal strength of the bond, it is advisable to leave the glue to dry overnight. This extended drying time ensures that the adhesive has fully cured and creates a stronger, more durable bond between the plastic surfaces.

Adequate drying time is essential to prevent weakening the bond or causing potential damage to the glued items. Impatience or rushing the process may result in the adhesive not reaching its full strength, compromising the integrity of the repair or joint. By allowing the glue to dry completely, you can be confident that the bond is secure and less likely to fail or break unexpectedly.

Additionally, certain adhesives may require specific conditions during the drying process. For example, some adhesives may need to be shielded from dust, moisture, or extreme temperatures to ensure proper curing. Others might necessitate clamping or securing the joined parts to prevent shifting or misalignment while the adhesive sets. Following any specific instructions provided by the manufacturer will help ensure a successful and robust bond between the plastic components.

Overall, allowing adequate drying time is critical when gluing plastic to plastic. By following the recommended drying times, handling the parts with care, and providing suitable conditions during the curing process, you can achieve a strong and long-lasting bond between the plastic surfaces.

Frequently asked questions

The easiest way to identify the type of plastic is to search for a recycling symbol on the plastic itself, the label, or the packaging the object came in. The recycling symbol consists of three arrows that form a triangle with a number in the middle. This number indicates the category of plastic and can help determine the best adhesive to use.

The three most common plastic adhesives are super glue, plastic bonding systems, and epoxy. Other adhesives include cyanoacrylate (CA) glue, plastic welds, and plastic cements.

Degrease the plastic with soap or isopropyl alcohol and dry thoroughly. Sand the plastics with 120-200 grit sandpaper to create a rough surface for the glue to bond to. Some plastic bonding systems include an activator as a preliminary step to prepare the surface and create a stronger bond.

Use a clamp, tape, or rubber bands to hold the plastic pieces together until the adhesive dries. Leaving the glue to dry overnight will typically yield the best results.
