Plastic injection molding is a popular manufacturing process, with the majority of plastic products today being manufactured by injection molding. The process involves injecting molten plastic into a mold, which then cools and hardens to create a solid plastic object. Injection molding is a great way to make multiple copies of a part quickly and can be used to create a wide variety of objects, from simple shapes to complex designs. Building an injection mold can be a challenging task due to the nuanced design, material, and process requirements involved. This process requires careful planning and consideration of factors such as production needs, resin selection, and part design to ensure a successful outcome.
| Characteristics | Values |
|---|---|
| Cost | Between $100 and $200 depending on where the metal is purchased |
| Design | Must take shrinkage, ejection, and part design into account |
| Materials | Epoxy, aluminium, steel, silicone, resin, plastic |
| Tools | 3D printer, foundry, respirator, gloves, leather apron, closed shoes, welding gloves, face mask, fire extinguisher, bucket of sand |
| Techniques | CNC machining, stereolithography (SLA) |
Explore related products
What You'll Learn
Design and production considerations
The design and production considerations when building a plastic injection mould are critical to the success of the project. Here are some key factors to keep in mind:
Design Considerations:
- Part Design Compatibility: Ensure the part design is compatible with the selected resin(s) and injection pressure. Consider the resin's ability to flow into the mould and the pressure required to inject the molten plastic.
- Cooling and Finish: Anticipate potential challenges related to cooling and finishing. Minor changes to the part design or resin selection may resolve these issues.
- Tolerances: Understand the part's tolerances and how they affect tooling. Changing the material selection, adding quality checks, or creating a more complex mould may be necessary.
- Performance Requirements: Consider how the design takes into account the part's performance requirements, balancing lead time and cost.
- Shrink Rate: Account for the shrink rate of the plastic material used, typically ranging from 0.4% to 2%. The design must accommodate shrinkage to ensure successful part ejection.
- Ejection Systems: Choose an appropriate ejection system that considers cycle time and final product quality.
- Multi-Colour/Material Moulding: If using multiple colours or materials, build a mould that supports 2k/double- or multi-shot moulding, allowing for simultaneous injection.
- Draft and Radii: Apply draft and radii to enhance part ejection and reduce the risk of warping or breakage. Rounded corners improve plastic flow and reduce stress concentrations.
- Wall Thickness: Control wall thickness to manage cosmetics, weight, and strength. Avoid excessive thickness, which can cause sink marks, warp, and internal voids.
- Gating and Ejector Pins: Strategically place gating and ejector pins to facilitate the entry of plastic resin and effective ejection of parts. Tab gates are commonly used for their processing capabilities and size adjustability.
- Gate Type and Design: Understand the impact of gate type and design on part packing, gate removal, cosmetic appearance, and part dimensions. Consider manually trimmed or automatically trimmed gates and their respective advantages.
Production Considerations:
- Production Needs: Assess production needs, including volume and lifespan, to determine the selection of metal for the mould and the mould design. Adding more cavities per mould can increase efficiency for higher production volumes.
- Cost Implications: Minimising costs is essential, but ensure that cost savings do not compromise mould maintenance, part quality, or production efficiency.
- Tooling and DFx: Incorporate Design for Manufacturing (DFM) early in the project to address critical details of the injection moulding process. Consider DFx for a comprehensive approach, including reliability, regulatory requirements, cost, and supply chain.
- Final Assembly: Optimise the design for assembly and kitting, ensuring it meets necessary certifications, quality requirements, and cost constraints.
- Construction Method: Choose between Computer Numerical Control (CNC) machining and Electrical Discharge Machining (EDM) for mould construction. CNC machining is automated and follows programmed instructions, while EDM uses an electrode to shape the mould without touching it.
These design and production considerations will help guide the successful building of a plastic injection mould, ensuring a cost-effective, efficient, and high-quality outcome.
