Story drift, also known as inter-story drift, is a deflection of a single story relative to the base or ground level of a structure. It is important to understand story displacement to comprehend story drift. The drift index varies significantly over the height of the structure, and the maximum interstory drift index is usually more than twice the global drift index. To evaluate the story drift, it is necessary to create a centre of gravity for each story as a node. The story drift is then determined at the top and bottom edges of the story. There are four loading cases to consider when determining the design story drift per Chapter 12.8.6 of ASCE 7-10. The story drift can be calculated and reported based on calculated displacements in the X-direction.
| Characteristics | Values |
|---|---|
| Story drift determination | Create a center of gravity for each story as a node |
| Story displacement | Deflection of a single story relative to the base or ground level of the structure |
| Seismic drift | Depends on the code and country but are usually given directly in the code |
| Seismic design | Provide life safety (strength and ductility) and damage control (serviceability drift limits) |
| Plastic hinge development | Studied via elastic-plastic time history analysis |
| Plastic story drift | Depends on the story height, usually represented as "h" or "H" |
| Inter-story drift | Calculated based on displacements in the X-direction |
| Maximum story drift | Calculated for each mode shape individually for each direction |
Explore related products
What You'll Learn
- Understand story displacement, the deflection of a single story relative to the base or ground level of the structure
- Consult building code documents for your area, such as ASCE 7-16
- Calculate inter-story drift using specific software, like RISA or SkyCiv
- Consider seismic design forces and loading cases, especially for taller structures
- Account for the redundancy factor (rho) and the Direct Analysis Method
Understand story displacement, the deflection of a single story relative to the base or ground level of the structure
To understand story drift, also known as inter-story drift, we must first understand story displacement. Story displacement is the deflection of a single story relative to the base or ground level of the structure. As we move up the structure, we can expect higher total displacement values. In SkyCiv Structural 3D, these values are shown as the X, Y, or Z-axis displacements, depending on the specific structure's lateral directions.
Story drift is the deflection of a single story relative to the previous story. Story drift is relative to the nearby levels, so we can expect a different-looking graph when comparing story drift to the height of the structure. The calculation of story drift is simple: to find the story drift of level "X", subtract the story displacement of level "X-1" from the story displacement of level "X". For example, the story drift of level 4 is the total story displacement of level 4 minus the story displacement of level 3. Story drift is sometimes shown as a ratio, dividing the story drift value by the story height.
When considering the limits and allowable story drift, the type of force causing the deflection is important. Seismic forces have more rigorous limits, which depend on the code and country but are usually given directly in the code. For wind loads, ASCE 7 does not impose an allowable drift limit, but there are common practices and commentary that engineers should consider. Common values of inter-story drift range from H/200 to H/600, with the most common limit being H/400.
The story drift ratio, as required by the code, must be checked against the limit of 2.0% under earthquakes. The story drift ratio around the intermediate level of the building is typically more critical than at the top. Additionally, the importance of story drift is in the design of partitions and curtain walls.
