Plastic electrical boxes are the most common choice for residential wiring projects due to their affordability, ease of installation, and lightweight nature. When sizing a plastic electrical box, it is important to consider the number of wires and devices that will be housed within it. Single-gang boxes, for instance, are suitable for individual switches or outlets, whereas double-gang boxes can accommodate two devices side by side. The specific use case of the box will also determine the features required, such as fan-rated boxes for ceiling installations or weatherproof boxes for outdoor setups. It is crucial to ensure that the box can handle the power requirements and environmental conditions of its installation location.
| Characteristics | Values |
|---|---|
| Purpose | Enclose wire connections and protect against short circuits |
| Types | Junction box, old work box, outdoor box, new work box |
| Old Work Box | Installed on drywall after it has been hung; ideal for adding new outlets to pre-existing walls |
| Outdoor Box | Protects wiring from the elements with gaskets, sealed seams, and watertight covers |
| Standard Shape | Rectangular, housing a single electrical switch or outlet |
| Standard Size | 4-inch square box, offering ample space for wire connections |
| Single-Gang Box | For a typical outlet or switch |
| Double-Gang Box | For two light switches or two duplex receptacle outlets |
| Round Pan Box | 1/2-inch deep, used for ceiling light fixtures, smoke alarms, and wall sconce light fixtures |
| Material | Plastic or metal |
| Plastic | Lightweight, easy to install, less expensive, non-conductive, reducing the risk of electrical shock |
| Metal | Better heat dissipation, durability, fire resistance, and grounding; required for proper grounding and bonding of the electrical system |
| Installation | Installed before drywall or other wall coverings are in place |
| Safety | Must be fitted with box covers; exterior covers must be watertight |
Explore related products
What You'll Learn
Plastic boxes are the most common choice for residential wiring projects
Plastic boxes are a good choice if you are working on a remodel or retrofitting an older home. They are lightweight and adjustable, which is helpful when fitting them into tricky spaces or walls that are easy to access. They are also great for quick fixes or updates. Plastic boxes come with built-in clamps for the wires, further lowering the overall project cost. Many plastic boxes also come with pre-attached nails for nailing into studs. Presets on the box indicate the thickness of 1/2-inch drywall to help prevent the installer from nailing the box face flush with the stud.
However, it is important to note that plastic boxes cannot be disassembled and reassembled to gang them into double or triple-sized boxes. Plastic boxes are also not suitable for heavy-duty work or industrial spaces. They are not fireproof and may melt when subjected to sufficiently high temperatures.
When selecting an electrical box, it is important to consider the construction, wiring method, devices, location, and safety. Old work boxes are designed to be installed in finished walls and are a good option when access to studs is limited. Single-gang boxes hold one electrical device, such as a switch or receptacle, while double-gang boxes accommodate two electrical devices side by side. The size of the electrical box should also be chosen based on the number of wires it needs to accommodate, as each gauge of wire requires a certain amount of cubic inches of available electrical box space.
Aging White Plastic: Techniques for an Antique Look
You may want to see also
Explore related products
Old work boxes are designed to be installed in finished walls
Electrical boxes, also known as junction boxes, are used to enclose wire connections. They come in a variety of sizes and styles and are designed to fit wherever you need them. Old work boxes, also called "remodeling boxes" or "retrofit boxes", are specifically designed to be installed on walls that are already finished.
Old work boxes are typically used when you need to add new outlets or extend an existing circuit in a room with pre-existing walls. Since the walls are already finished, old work boxes cannot be attached directly to studs. Instead, they use a clever fastening system with retention tabs and mounting ears located at opposite corners of the box. Once the box is inserted into the wall cutout and the screws are tightened, the rear retention tabs open up and press against the back of the drywall, while the mounting ears press against the front of the wall, essentially "pinching" the box in place.
To install an old work box, first, create a wall cutout by marking the exact position where the box will be installed. Then, run the cables to the new box location, ensuring that there is 8 to 12 inches of excess cable at the wall opening. Strip 8 to 12 inches of sheathing from the cable and connect it to the box, ensuring that 1/2 inch of sheathing is visible inside the box. Test the clamping mechanism by tugging on the cable to ensure it is tightly clamped.
Finally, push the box into the wall cutout. If it fits tightly, do not force it to avoid damaging the drywall. Tighten the screws until you feel resistance and the box is firmly attached to the wall. Old work boxes made from PVC may have integrated quick-clamping systems, which can be difficult to open. To make it easier, use a flat-blade screwdriver to pry up the clamping tab by about 1/4 inch, loosening the clamp and making it easier to insert the cable.
Plastic and Pregnancy: What's Safe?
You may want to see also
Explore related products
Single-gang boxes hold one electrical device
Single-gang boxes are a standard type of electrical box used in homes. They are typically used to hold a single electrical device, such as a light switch or outlet. Single-gang boxes are usually rectangular and measure about 2 inches by 4 inches, with depths ranging from 1-1/2 inches to 3-1/2 inches. They can be made of metal or plastic, with some varieties featuring built-in cable clamps for securing cables.
When selecting a single-gang box, it is important to consider the number of wires that will be placed inside. Each wire gauge requires a certain amount of cubic inches of space, and the box must have sufficient space to accommodate the device being used. It is also crucial to ensure that the box is installed correctly and safely. Single-gang boxes are typically used in new construction or renovation projects, and they should be placed in accessible locations to allow for future maintenance or repairs.
Single-gang boxes are commonly used for light switches and power outlets. Light switches are typically installed at a height of 42 inches from the floor, while power outlets are usually placed at a height of 12 inches from the floor. It is important to plan the placement of these boxes carefully, considering factors such as the location of studs and the need for clearances.
Additionally, it is worth noting that electrical boxes are categorized by the number of devices they can accommodate. While single-gang boxes are suitable for individual devices, double-gang boxes can hold two devices side by side, and larger multi-gang boxes can accommodate three or more devices. The choice between these options depends on the specific wiring needs and the number of devices required for the project.
Installing Hub Centric Rings: A Step-by-Step Guide
You may want to see also
Explore related products
Double-gang boxes accommodate two electrical devices side by side
Electrical boxes, also known as junction boxes, enclose wire connections and protect against short circuits, which can cause fires. They come in many shapes and sizes to fit different installation needs.
A square electrical box, also known as a double-gang box, is a type of electrical box that can accommodate two electrical devices side by side. This type of box is typically used to house two devices, such as light switches or outlets, and comes in metal or non-metallic units.
When choosing a double-gang box, it is important to consider the size and number of devices that need to be accommodated. The space allowance for a switch or receptacle is based on the size of the device, and the term used to describe this is a "strap". Each strap is the size of a standard switch or receptacle, and the number of straps needed depends on the size of the device.
Additionally, it is important to ensure that the electrical box has enough space for all the wires that need to be connected. The number of wires in the electrical box should never exceed its safe fill capacity. Each gauge of wire requires a certain amount of cubic inches of space, so it is important to consider this when choosing the size of the electrical box.
When installing a double-gang box, it is important to follow the proper procedures. For new construction installations, it is necessary to diagram the room and ensure that there are enough electrical boxes to accommodate all the light switches, outlets, and fixtures. It is also important to make sure that the electrical box sizes match the locations where they will be installed. When working in finished areas, a stud finder can be used to locate studs and ensure they do not interfere with the placement of the new box.
Revamp Your Plastic Flower Pots: Easy Distressing Techniques
You may want to see also
Explore related products
![[3 Pack] CLOUDY BAY Single Gang Electrical Outlet Box,14 Cubic Inch Junction Box,Old Work Box,UL Listed](https://m.media-amazon.com/images/I/71DLDomxBiL._AC_UL320_.jpg)
Outdoor boxes protect wiring from the elements
Electrical boxes, also known as junction boxes, are used to enclose wire connections and protect against short circuits, which can cause fires. They come in a variety of shapes and sizes, with the standard rectangular shape being the most common.
Outdoor electrical boxes are essential for protecting wiring from the elements. They are typically made of metal or plastic and are designed to keep out rain, snow, and other environmental factors. When choosing an outdoor electrical box, it's important to consider the size, shape, and material that best suits your needs.
Metal junction boxes are typically used when electrical connectors require RFI shielding or when using a metal-sheathed cable. They are also better suited to outdoor use as they can withstand harsh weather conditions. Plastic junction boxes, on the other hand, are commonly used for applications with non-metallic cables and cable clamps. While plastic boxes made from PVC are common for residential use, they may not be durable enough for outdoor applications. In such cases, polycarbonate plastic boxes offer a more robust solution.
To ensure the wiring is protected from the elements, outdoor electrical boxes feature sealed enclosures with gaskets, sealed seams, and watertight covers. Weatherproof covers and enclosures are crucial for keeping moisture and debris out of the electrical box. Gaskets provide critical protection against water ingress, and NEMA or IP ratings can help guide you in choosing an enclosure with the right protective features.
When installing outdoor electrical boxes, it's important to follow safety measures. Ensure that the box is fitted with a cover, as required by electrical codes. Keep the cover closed when the outlet is not in use, and only open it when plugging in devices. Additionally, consider installing GFCI outlets (Ground Fault Circuit Interrupters) that automatically shut off the power if a ground fault is detected, preventing electrical sparks that could be hazardous.
Recycling Plastic and Cardboard: What's the Deal?
You may want to see also
Frequently asked questions
Plastic electrical boxes are categorized by the number of devices they can accommodate. Single-gang boxes hold one electrical device, such as a switch or outlet. Double-gang boxes hold two electrical devices side by side. There are also multi-gang boxes that can accommodate three or more devices.
The size of the plastic electrical box you need depends on the number of wires you need to accommodate and the space required for the devices you plan to install. Each gauge of wire requires a certain amount of cubic inches of available electrical box space. If the box will house a switch or receptacle, you must also account for the space allowance of the device.
The standard sizes of plastic electrical boxes are 22-cu.-in. 4-in. round, 22-cu.-in. single-gang, and 32-cu.-in. double-gang. The 22-cu.-in. 4-in. round box is typically used for ceiling light fixtures, smoke alarms, carbon monoxide detectors, and wall sconces. The 22-cu.-in. single-gang box is used for a typical outlet or switch, while the 32-cu.-in. double-gang box is used for two light switches or two duplex receptacle outlets.
Yes, new construction projects typically use new work boxes, which are designed to be installed before drywall or other wall coverings are in place. Remodeling projects typically use old work boxes, which are designed for finished walls and can be installed without affecting the drywall.
