Plasticizers are substances added to raw polymers like plastics and rubber to improve flexibility, ease of shaping, and moulding, and to reduce friction on their surface. They are commonly added to polymers and plastics such as PVC, to improve handling during fabrication or to meet the demands of the end product's application. Testing for plasticizers in rubber is important for confirming the composition of raw materials and finished products, and can be done through a variety of methods including Gas Chromatography Mass Spectrometry (GC-MS) and ASTM D2199-03.
| Characteristics | Values |
|---|---|
| Purpose of Testing | Confirming the composition of raw materials and finished products, regulatory purposes, identifying unknown plasticizers, or quantitative analysis of known plasticizers |
| Sample Size | 1 to 5 grams |
| Testing Method | Gas Chromatography Mass Spectrometry (GC-MS) |
| Plasticizer Migration | Responsible for premature coating failure in polyvinyl chloride (PVC) synthetic materials; standard assays measure migration rate under varying scenarios |
| Plasticizer Loss | Through diffusion and evaporation from plastic or rubber products, leading to poorer mechanical properties and environmental contamination |
| Plasticizer Function | Added to raw polymers to improve flexibility, ease of shaping and molding, and reduce friction |
| Plasticizer Types | Phthalates, Dicarbonates, Phosphates, Fatty Acid Esters, Sebacates, Adipates, Terephthalates, etc. |
| Safety | Registration for Evaluation, Authorisation, and Restriction of Chemicals (REACH) and FDA have determined most plasticizers to be safe |
Explore related products
What You'll Learn
Gas Chromatography Mass Spectrometry (GC-MS)
The GC-MS technique is particularly effective for analyzing substances such as polymers, microplastics, rubber, paints, dyes, resins, coatings, cellulose, wood, textiles, and oils. By applying heat to break down samples, GC-MS enables the analysis of compounds that may not be suitable for conventional gas chromatography–mass spectrometry. By heating the sample mixture to the point of thermal degradation, the smaller molecules can be separated by gas chromatography and identified by mass spectrometry.
The GC-MS system is often used for the automatic pyrolysis of polymer materials. Thermal desorption combined with gas chromatography is a simple yet powerful tool that can quickly extract low levels of volatile organic compounds (VOCs) from a wide range of solid matrices, including polymers and adhesives. The addition of a pyrolysis module to the toolkit enables analysts to gain a deeper understanding of the structure of the polymer or adhesive material.
The standard analysis procedure for plasticizers typically involves solvent extraction followed by GC or GC-MS identification. However, a novel technique, direct thermodesorption, has been developed to overcome the challenges associated with solvent contamination. By combining a new thermodesorption module with a cooled injection system, the direct thermodesorption GC-MS method provides a powerful system for the direct analysis of volatile trace compounds in gaseous, liquid, and solid samples. This technique is not only easy to perform but also eliminates the risk of cross-contamination.
Pyrolysis GC-MS has been specifically used to determine additives in polymers and assess their compatibility with adhesives. For example, it was used to determine the plasticizer used in a PVC carrier film, revealing the presence of polyurethane and hexamethylene diisocyanate (HDI or HMDI). This information helped deem the plasticizer compatible with the adhesive.
The Perfect Plastic Minnow Hooking Technique
You may want to see also
Explore related products
Testing for plasticizer migration
Plasticizers are substances added to materials to increase their plasticity, decrease their viscosity, and reduce friction during handling in manufacture. They are commonly added to polymers and plastics, especially polyvinyl chloride (PVC), to improve their usability. However, plasticizer migration can lead to undesirable effects, such as reduced tensile strength, pollution, toxicity, and environmental risks. Therefore, testing for plasticizer migration is essential to ensure the durability and safety of products containing these materials.
One common method for determining plasticizer migration is ASTM D2199-03. In this test, a lacquer film is flattened on a glass panel and covered with a PVC synthetic material specimen, ensuring the PVC coating surface is in close contact with the film. The specimen is then sequentially covered with foil, sponge rubber, glass, and a 910g weight. The assembly is incubated at 50°C for 72 hours. After incubation, the specimen is removed, and the PVC coating surface is wiped with a soft rag dampened with heptane. The level of plasticizer exudation can be assessed by examining the lacquer film for any marring or softening.
Another standardized procedure, ASTM D3291-11, allows for the qualitative determination of plasticizer exudation tendency due to compressional stress. In this test, conditioned PVC specimens are folded in half, with the short ends together, and placed in a chamber at 23°C ± 2°C with a relative humidity of 50% ± 10%. At fixed intervals, the specimen is removed, bent 360° in the opposite direction, and the former inside of the loop is examined by wiping with a cigarette paper. The likelihood of exudation can be rated on a scale from 0 to 3, with a higher score indicating a greater tendency for the plasticizer to migrate.
Additionally, the fogging test and activated carbon method are commonly employed in the automobile industry to evaluate the volatilization propensity of plasticizers from PVC synthetic materials. "Fogging" refers to the heating-induced evaporation of volatile components from PVC, textiles, or leather used in motor vehicle interiors, which can impair the driver's visibility and endanger passenger safety.
To quantitatively analyse plasticizers present in a polymer, an extraction is performed to remove the plasticizer from the resin using an organic solvent. The extract is then typically analysed using Gas Chromatography Mass Spectrometry (GC-MS). This method is highly sensitive and can detect both intentional and trace amounts of plasticizers resulting from contamination.
Realigning a Plastic Zipper: A Quick Fix Guide
You may want to see also
Explore related products
Screening for unknown plasticizers
One standard method for determining plasticizer migration from polyvinyl chloride (PVC) synthetic materials is ISO 177:2016(E). This method specifies a standardized procedure to evaluate the exudation tendency of plasticizers from PVC coatings into other materials in physical contact. The PVC synthetic materials are cut into discs of a specific size, typically 50 mm ± 1 mm in diameter and at least 0.5 mm in thickness. The discs are then superposed with the uncoated surfaces in contact and the coated surfaces facing outwards. These superposed specimens are then placed between two absorbent backing discs capable of absorbing plasticizers, such as standard rubber or additive-free alternatives.
Another method for measuring plasticizer exudation is ASTM D2199-03. In this procedure, a lacquer film is flattened on a glass panel and covered by a PVC synthetic material specimen, ensuring the PVC coating surface is in close contact with the film. The specimen is then sequentially covered with a foil, sponge rubber, glass, and a weight of 910 grams. The entire assembly is then incubated at 50 °C for 72 hours. After incubation, the specimen is removed, and the PVC coating surface is wiped with a soft rag dampened with heptane. The level of plasticizer exudation can be assessed by examining the lacquer film for any marring or softening.
Nuclear magnetic resonance and computational simulation are advanced techniques that can also be used to screen for migration-resistant plasticizers. These methods offer advantages in terms of labour and time savings compared to conventional assays.
Transform Your Plastic Playhouse With a Fresh Coat of Paint
You may want to see also
Explore related products
Quantitative analysis of known plasticizers
Plasticizer analysis is important for confirming the composition of raw materials and finished products. It can also be of interest for regulatory purposes. To perform quantitative analysis of known plasticizers, an extraction is initially performed to remove the plasticizer from the resin using an organic solvent. The extract is then typically analyzed by Gas Chromatography Mass Spectrometry (GC-MS).
GC-MS is widely used in the qualitative and quantitative analysis of plasticizers. It has been used to successfully quantify the exudation of plasticizers. However, component loss and cross-contamination during the transfer process may lead to deviations in test results. When using EI ionization mode, multiple ion fragments may be formed, resulting in complex mass spectra and difficulties in analysis.
High-Performance Liquid Chromatography-Mass Spectrometry (HPLC-MS) is another method for quantitative analysis. It offers high sensitivity and good selectivity. The multiple reaction monitoring (MRM) mode in HPLC-MS reduces interference caused by different ions under test with the same retention time, improving detection sensitivity.
Other methodologies for quantitative assessment of plasticizer migration have been established by organizations such as the German Institute for Standardization (DIN), International Organization for Standardization (ISO), and American Society for Testing and Materials (ASTM). These methods have been subject to Inter-Laboratory Studies, demonstrating the reliability and repeatability of the test results.
In the context of plasticizer migration from PVC synthetic materials, the fogging test and activated carbon method are commonly employed for quantitative evaluation of the volatilization propensity of plasticizers. The fogging test is particularly relevant in the automobile industry, where heating-induced evaporation of PVC components can condense on the windshield, impairing visibility and endangering passenger safety.
Launching a Plastic Empire: A Beginner's Guide
You may want to see also
Explore related products
Evaluating plasticizer compatibility
Plasticizers are substances added to materials to increase their plasticity, decrease their viscosity, and reduce friction during handling in manufacturing. They are commonly added to polymers and plastics, such as PVC, to improve their usability and meet the demands of the end product's application.
When evaluating plasticizer compatibility, it is essential to consider the specific type of rubber or polymer and the desired attributes of the final product. Here are some key factors to consider:
Compatibility and Performance Attributes:
Compatibility and performance are critical factors when developing a rubber formulation for a specific application. Plasticizers are chosen based on their compatibility with the host material, low toxicity, non-volatility, and cost-effectiveness. For example, sebacate-based plasticizers are highly compatible with various synthetic rubbers, including nitrile rubber and neoprene, and offer superior properties at low temperatures.
Plasticizer Migration:
Plasticizer migration is the movement of plasticizers from one material to another. It can lead to premature coating failure in polyvinyl chloride (PVC) synthetic materials. Standard assays that measure the migration rate of plasticizers under different conditions are essential for comparing the durability of PVC-derived products. Understanding plasticizer migration is also crucial for predicting the short- and long-term performance of plasticized polymers and developing methods to hinder migration.
Plasticizer Loss:
Plasticizers can be lost from rubber and plastic products through diffusion and evaporation, leading to degraded mechanical properties and environmental contamination. Evaluating plasticizer compatibility should consider the mechanisms and kinetics of plasticizer loss under various conditions, such as temperature and ageing. Techniques like thermogravimetry, infrared spectroscopy, and chromatography can be used to measure plasticizer concentration and predict the lifetime of products.
Plasticizer Selection for Elastomers:
The choice of plasticizer depends on the specific elastomer and the desired properties. For instance, plasticizers are added to elastomers like acrylonitrile butadiene rubber (NBR) to extend softness and reduce mixing time. A wide range of ester plasticizers, including adipates, phthalates, and epoxidized soybean oil, are compatible with NBR. Chlorinated polyethylene (CPE) is compatible with various plasticizers, including general options like DINP and specialty choices like TOTM.
In summary, evaluating plasticizer compatibility involves considering the specific material, desired performance attributes, potential for migration and loss, and the selection of appropriate plasticizers for the given application.
Hemp Plastic: Breakdown Speed and Eco-Benefits
You may want to see also
Frequently asked questions
A plasticizer is a substance added to materials like rubber and plastic to make them softer, more flexible, and easier to handle and mould.
Plasticizer analysis is important to confirm the composition of raw materials and finished products. It can also be useful for regulatory purposes.
Testing for plasticizers in rubber can be done through methods such as Gas Chromatography Mass Spectrometry (GC-MS) or ASTM D2199-03. GC-MS involves extracting the plasticizer from the resin using an organic solvent, while ASTM D2199-03 involves flattening a lacquer film on a glass panel, covering it with the rubber specimen, and then incubating it. Other methods include evaluating plasticizer migration and identifying the presence of common plasticizers like phthalates and fatty acid esters.
