Antennas are used in a variety of devices, from radio and television to Wi-Fi and GPS. They can be made of metal or plastic, with plastic antennas often being smaller and encased in a plastic cover. This cover can provide structural support and protection against detuning, as well as preventing corrosion in the case of copper wire antennas. The effectiveness of an antenna depends on its size in comparison to the radio wave being received, with smaller antennas generally being less effective. Chip antennas are a type of small antenna that can be implemented using an SMD (Surface Mounted Device) chip antenna component or designed on a PCB (Printed Circuit Board). These chip antennas are commonly found in plastic devices and can be affected by the plastic surrounding them, with the thickness of the plastic and specific material impacting signal quality.
| Characteristics | Values |
|---|---|
| Name | Chip antennas |
| Other Names | Off-the-shelf chip antenna component, SMD (Surface Mounted Device) chip antenna component, PCB (Printed Circuit Board) |
| Use Cases | Internal antennas for IoT devices, wearables, and other plastic-covered devices |
| Performance | May experience issues due to plastic surrounding; can be optimized through matching component topology |
| Comparison with PCB Trace Antenna | PCB trace antenna is more efficient but more costly and susceptible to detuning |
| Signal Quality Factors | Thickness of plastic, specific material, shielding |
| Benefits of Plastic Covering | Structural support, protection against detuning, prevention of oxidation, reduction in required material |
| Drawbacks of Plastic Covering | Changes in resonant frequency, potential for detuning |
Explore related products
What You'll Learn
Chip antennas in plastic devices
Chip antennas are a type of internal antenna used in wireless devices. They can be implemented using an SMD (Surface Mounted Device) chip antenna component or designed on a PCB (Printed Circuit Board). These antennas are commonly used in IoT devices and wearables, which are often enclosed in plastic covers.
When designing a chip antenna for a plastic device, it is important to consider the impact of the plastic cover on the antenna's performance. The plastic cover can affect the antenna's return loss or VSWR, as well as its frequency band. In some cases, covering the antenna with a plastic surrounding can tune it to the wrong frequency band, as shown in the example of the "S1,1 ChipAnt Plastic RefComp", where the antenna was tuned to a frequency band of 550MHz to 700MHz instead of the intended 700MHz-960MHz.
To address this issue, antenna manufacturers provide instructions on changing the matching components in their technical datasheets or reference design boards. By altering the component topology or values, it is possible to improve the matching level and optimize the antenna's performance in a plastic surrounding.
Overall, while chip antennas in plastic devices may present some integration challenges, they offer flexibility in product design and enable the creation of compact and functional electronic devices.
